PAM8406 Digital Amplifier Module With Volume Control Potentiometer is an excellent noise suppression module. If you don’t receive input audio, you will not hear any noise on your ears. RoboticsBD
This module has a double channel stereo output. Its 5V power supply gives the output of 5W+5W power, can directly drive the 4 Omega, 8 Omega small sound box, the output power is big, the energy is full, the sound quality is good, with the volume adjustment of the right and left channel. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Excellent noise suppression. in the absence of contact input audio, you will not hear any noise even put your ear close to the speaker
- The two-channel stereo, 5V power supply can output 5W + 5W power, directly drive 4, 8 speakers, output power, full of energy, good sound quality, with left and right channel volume adjustment.
- Unique non-LC filter Class-D digital power board, it can be used directly for the USB-powered from computers.
- Dual-panel wiring and proper solution to potential balance and channel crosstalk caused by the wiring between
- Ultra-miniature design, it can easily be placed in a small space inside a variety of digital products, high amplification efficiency.
- Solder by machine
- The rated working voltage 2.5-5V, limit operating voltage 5.5V
- The unique D type digital power plate without LC filter can be directly powered by the USB of the computer.
- Double panel wiring, properly solves the ground potential balance caused by wiring and inter-channel crosstalk.
- The ultra micro design can be easily placed in the small space of various digital products, and the amplification efficiency is super high.
- The whole board is welded by machine. The welding quality is comparable to that of the manual soldering iron. RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Operating voltage (v) | 5 |
| Length (mm) | 25 |
| Width (mm) | 25 |
| Height (mm) | 12 |
| Weight (gm) | 3 |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 4 × 4 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x PAM8406 Digital Amplifier Module With Volume Control Potentiometer 5Wx2 Stereo.
