1 Meter Electrical Flexible Cable/ Wire - White

RBD-2822

  • Flexible-SC(FR) cable with 1x0.4 rm gauge size, white color, and flame-retardant insulation material.
  • Designed for electrical use in a variety of applications.
BDT 23.00
BDT 23.00 BDT 23.00 BDT 23.00 BDT 23.00
Tax included Tax excluded Tax included Tax excluded
BDT 23.00 Tax excluded
BDT 23.00 Tax included
BDT 0.00 Tax
BDT 23.00 Tax excluded
BDT 0.00 Tax
BDT 23.00 Tax included
Quantity
In-Stock
97 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

The Flexible-SC(FR) wire is a high-quality electrical wire designed for various electrical applications. Its flexible construction allows for easy installation in tight spaces, and its flame-retardant (FR) insulation material makes it safe and reliable to use. It is rated for 300/500V and is suitable for use in a wide range of electrical applications. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. Easily Solderable Copper Wire
  2. Wiring for light appliances
  3. Industrial control systems
  4. Automation systems
  5. Robotics
  6. Electronic Signaling
  7. As DC Motor Wire

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. Flexible construction for easy installation
  2. Flame-retardant (FR) insulation material for safety and reliability
  3. Rated for 300/500V
  4. Size: 0.4 rm (14/76)
  5. Flexible Stranded Copper
  6. Stranded copper conductor for improved conductivity
  7. PVC jacket material for durability and protection

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

What is the meaning of 0.4 rm or (14/76)?

When referring to 14/76, it means that there are 14 strands of cable with a diameter of 0.076 inches. This equals a diameter of 1.9304mm. In the US, this is similar to #12 AWG wire.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Product Name Flexible-SC(FR)
Reference Standard BDS-899
Voltage Grade 300/500V
Conductor Material Stranded Copper
Insulation Material Flame Retardant (FR)
Maximum Temperature Rating 90°C
Gauge Size 1x0.4 rm
Conductor Stranding 14/76
Shielding None
Jacket Material PVC
Color White
Length 1 meter
Shipment Weight 0.008 KG
Shipment Dimensions 16 x 2.5 x 2.5 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1 x 1 Meter Electrical Wire - White
