This soldering wire has good solderability, insulation resistance, no spattering, and non-corrosive. Widely used in electrical and electronics, solder parts like a circuit board, electronics devices, and others.
For high-reliability soldering, a good soldering lead is always needed. For this reason, we provide this original soldering lead for your daily use. Sometimes you will find that the solder job is very difficult because the solder wire does not melt fast enough to create a strong bond with the component. Because you have a cheap soldering iron and a cheap soldering wire. Soldering is an art. If you need to solder regularly, we suggest you buy a better quality soldering iron and soldering wire just like this one. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
60/40 solder, also known as alloy Sn60Pb40, consists of 60% tin and 40% lead, belonging to the soft solder category. Despite its melting point, closely resembling the eutectic temperature, it's classified as non-eutectic solder with a melting point at 190 degrees Celsius. This solder flows smoothly, making it user-friendly.
Renowned for excellent thermal and electrical conductivity, 60/40 solder forms robust, permanent metal bonds, ideal for electronics and PCB manufacturing. Proper storage in a non-corrosive, dry environment, ranging from 10 to 40 degrees Celsius, is crucial. However, its drawback lies in its non-eutectic nature and a relatively high melting range.
Suitable for joining copper and its alloys, it's less apt for shock or vibration-exposed joints. Offered in solid wires, acid core, and rosin core varieties, it's favored for dip soldering baths due to its narrow melting range.
60/40 solder proves perfect for electronic and electrical connections, compatible with heat sources like air-fuel torches and soldering guns. It complies with ASTM B32 Alloy Grade Sn 60 and J-STD-006 Sn60Pb40Sb0.4 standards. Being soft, it minimizes crack formation when joints encounter movement during cooling.
Features:
- Have been treated by special technology with oxide removal and antioxidant bearing.
- Easy to use, flows well, and heats evenly.
- Good solderability both in electrical conductivity and thermal conductivity.
- High activity flux makes more reliable soldering and leaves bright shiny solder joints after reflow.
- With the solder wire reel, soldering can be accomplished quickly.
- Widely applied in electrical repairs
| General Specification |
| Material |
Mix: 60% Sn / 40% Pb |
| Wire Diameter (mm) |
0.8 |
| Flux (%) |
Yes |
| Width (mm) |
|
| Height (mm) |
|
| Weight (gm) |
20 |
| Shipment Weight |
0.025 kg |
| Shipment Dimensions |
6 × 6 × 5 cm |
Please allow 5% measuring deviation due to manual measurement.
Package Includes:
1 x Premium 60/40 Sn Pb Tin Soldering Lead with Rosin 20g Low Melting Point
