The BC550 Transistor is a general purpose N-P-N transistor, in which N-P-N transistor electrons work as the primary charge carriers that are emitted from the emitter of the transistor to the PN junction. When a positive voltage is applied to the base holes are created to the base so they start migrating to the emitter junction, this process thins out the depletion region from PN junction and more and more electrons start flowing to the and all of those electrons are collected by the collector. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Application
- Switching relates and LEds
- PWM driven application
- LED dimmers or flashers
- Switching Applications
- Preamplifier for Power Amplifier
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Collector−Base Voltage VCBO |
50 |
| Collector−Emitter Voltage VCEO |
45 |
| Emitter-Base Voltage VEBO |
5 |
| Product Type |
NPN epitaxial silicon transistor bc546 bc547 bc548 bc549 bc550 |
| Operating Temperature Range (°C) |
–55° C to +125° C |
| Mounting Type |
Through Hole |
| Shipment Weight |
0.005 kg |
| Shipment Dimensions |
3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
- Datasheet
Package Includes:
1 x BC550 NPN Transistor .
