TTC5200

Reference RBD-1477

Transistor Silicon NPN Triple Diffused Type
Package/Case: DIP-16
TTC5200 IGBT

Description
Product Details

Description

Transistor Silicon NPN Triple Diffused Type TTC5200. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

Power Amplifier Applications

Features:

High collector voltage: VCEO = 230 V (min)
Complementary to TTA1943
Recommended for 100-W high-fidelity audio frequency amplifier output stage.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Brand	Toshiba
Transistor Type	NPN
Maximum DC Collector Current	15 A
Maximum Collector Emitter Voltage	230 V
Mounting Type	Through Hole
Maximum Power Dissipation	150 W
Minimum DC Current Gain	35
Maximum Emitter Base Voltage	5 V
Maximum Operating Frequency	30 MHz
No of pin	3
Dimension	20.5 x 5.2 x 26mm
Shipment Weight	0.005 kg
Shipment Dimensions	3 × 3 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

Datasheet

Package Includes:

1 x TTC5200

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details

Reference RBD-1477

In stock 106 Items

Specific References

EAN13: 1477
