IC Base Sockets 8 Pin

Reference RBD-1501

6 pins.
JDEC compliant.
Molded notch for proper orientation.
Easy to insert and remove ICs.

Description
Product Details

Description

8 Pin IC Socket base adaptor is an 8 pin IC holder, which can be soldered directly onto the PCB. The IC can be removed from this socket when required. The IC is placed on the socket at the time of use. This base acts as a removable IC holder. RoboticsBD

The socket is used when the IC is temperature sensitive and the heat from the soldering iron can damage the IC. This socket is used when working with a microcontroller IC and can be removed for programming. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

8 pins.
JDEC compliant.
Molded notch for proper orientation.
Easy to insert and remove ICs.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Current Handling Capacity (A)	1
No. of Contact Points	8
Contact Material	Phosphor Bronze
Contact Plating	Tin
Operating Temperature Range (°C)	-25 to 85
Flammability Rating	UL94V-0
Color	Black
Insertion Force	340g max per contact
Exertion Force	80g max per contact
Length (mm)	10
Width (mm)	10
Height (mm)	4
Weight (gm)	1 (approx) (each)
Shipment Weight	0.005 kg
Shipment Dimensions	3 × 3 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Included:

1 x IC Base sockets 8 pin

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details

Reference RBD-1501

In stock 221 Items

Specific References

EAN13: 1501
