Veroboard is the original prototyping board. Sometimes referred to as ‘stripboard’ or ‘matrix board’ these offer total flexibility for hard wiring discrete components. Manufactured from a copper clad laminate board or Epoxy based substrate – Veroboard is an ideal base for circuit construction and offers even greater adaptability using our range of terminal pins and assemblies. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Prototyping
- PCB Designing
- Basic Electronics
- Soldering
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Single Sided copper on SRBP base material
- Ideal circuit development board for hard wiring discrete components
- Hole diameters are 0.040 inch or 1.02mm nominal. RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Board Type | Vero Board DOT Type |
| Dimensions (mm) | 145 x 65 x 3 |
| Weight | 5 grams |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 15 × 7 × 1 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
Difference Between DOT and LINE Type:
This is a DOT Type Veroboard where every hole is individual.
This is a Line Type Veroboard where holes are connected in line.
Package Includes:
1 x Veroboard DOT Type
