This module is ideally suited to adding smoke sensing to your project. This is a detection module which can detect smoke particles to trigger a switch like response. This allows you to replace those mechanical switches that have been holding back your project all this time with something a little smellier. Featured By RoboticsBD.
An onboard potentiometer allows you to adjust the trigger volume so that you can tailor sensitivity to account for the projects surrounding background levels. Featured By RoboticsBD.
As a simple module it will suit use within a large range of projects based on microcontrollers such as Arduino boards and the Raspberry Pi. The module has a M3 mounting holes allowing for its easy attachment to a multitude of surfaces.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: Product images/ Components brand may vary from actual product as our stock rotates.
Note: PCB might be different from the picture as per stock
Pins:
- VCC ↔ 5V
- GND ↔ power supply ground
- DOUT ↔ MCU.IO (digital output)
Features:
- Power supply needs: 5V
- A gas, natural gas, city gas, smoke better sensitivity.
- There are screw holes for easy positioning
- Has a long life and reliable stability
- Rapid response and recovery characteristics
- DO output: TTL digital 0 and 1 (0.1 and 5V)
- Detectable concentration: 300-10000ppm
| General Specification |
| Type | Sensor |
| Material | PCB |
| Output Voltage | 5V |
| Compatible | Arduino |
| Size | 4.5 x 2 x 1.6 |
| Weigh | 0.008 kg |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
Documentation:
- Datasheet
Package Includes:
1 x MQ-2 Gas sensor Module
