Professional LCD molding resin: Optimize the formation of LCD low light source and printing efficiency is higher than the market compatible DLP / LCD / SLA resin. The resin is only designed for the LCD model of the resin, not recommended DLP or SLA machine. RoboticsBD
High-speed solidify: This resin ensures the strength of molded parts and not excessive shrinkage, but also improve print speed, shorten the curing time and enhance the printing efficiency of LCD machines as much as possible. RoboticsBD
Strong adhesion of the model and easy to detach after forming: Not only high success rate of printing and precision, but also to minimize resin release force and adhesion, so that the model attached to the forming platform can easily shovel and low viscosity makes it easier to clean the machine and model.
The material is rigid and tough: Strong material in the shovel model can easily lead to the model fragmentation, but too flexible material will be prone to the details of the print tensile deformation or fracture, which will affect the molding accuracy and aesthetics. RoboticsBD
Model's performance is stable: The resin is stable under different climatic conditions and is also easy to store, overcoming the shortcomings of other resins easily damp softening and environmental corrosion. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Parameter information:
- Main material: resin monomer & photo initiator
- Exposure parameters: Bottom exposure time(s) 20-60s, normal exposure time(s) 5-15s
Precautions Storage method:
- Keep away from light seals at room temperature (sunshine contains a lot of UV light, will solidify photosensitive resin. After testing, the light is not affected as long as it is not UV light).
- It is recommended to save at 15 ℃ -35 ℃ ambient temperature, the lower the temperature, the higher the viscosity of the resin. Sealed storage, excessive dust or moisture can affect print quality. Sunshine contains a lot of UV light, will solidify photosensitive resin.
Precautions Usage:
- Shake well before use, prohibiting the use of resin in places where there is a lot of sunlight.
- Wear gloves before use to avoid direct contact with the skin and keep the room ventilated.
- Inadvertent contact, as soon as possible to use a lot of water rinse. If you feel unwell, seek timely medical attention.
- Printed models need to use high-concentration alcohol to clean about 30S (recommended concentration of 95% or more, the higher the better).
- Do not pour the resin in the resin vat into the unused resin, do not leave the resin in the resin vat for a long time without use to avoid resin pollution affect the printing effect(long time without the resin can be introduced into airtight containers or sealed with plastic wrap shading save).
- Resin has a shelf life of up to 18 months.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Main Material |
Resin + Photoinitiator |
| Capacity |
500mL |
| Solidify wavelength |
405nm |
| Shelf life |
12 months |
| Hardness (D) |
79 |
| Viscosity |
552.0 mpa.s |
| Liquid Density |
1.100 g/cm^3 |
| Solid Density |
1.184 g/cm^3 |
| Tensile Strength |
23.4 Mpa |
| Elongation |
14.20% |
| Shipment Weight |
0.696 kg |
| Shipment Dimensions |
23 × 13 × 1 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The ANYCUBIC resin is most suitable for the Photon series 3D printer.
- The light source design, exposure time and other printing parameters of different brands of LCD 3D printers are different. The resin composition ratio of ANYCUBIC designed for the photon is special , it is the most consistent with resin photon print parameter.
Package Includes:
1 x Colored UV Resin 500mL Black.
