5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3
  • 5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3
  • 5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3
  • 5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3

5 axis CNC Breakout Board with optical coupler For Stepper Motor Driver MACH3

RBD-0565

  • Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
  • USB power supply and peripherals power phase are separate to protect computer security.
  • All the signals are to-isolate which can protect your computer security.
  • 5-input interface to define the Limit, Emergence-Stop, Cutter alignment, etc.
  • Wide input voltage range: 12-24V, and with anti-reverse function. RoboticsBD
  • One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
BDT 3,500.00
BDT 3,500.00 BDT 3,500.00 BDT 3,500.00 BDT 3,500.00
Tax included Tax excluded Tax included Tax excluded
BDT 3,500.00 Tax excluded
BDT 3,500.00 Tax included
BDT 0.00 Tax
BDT 3,500.00 Tax excluded
BDT 0.00 Tax
BDT 3,500.00 Tax included
Quantity
In-Stock
11 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

MACH3 Interface Board CNC 5 Axis with Optocoupler latest upgrade 5 axis breakout board is specially designed for the CNC single axis 2-phase stepper driver controller, such as TB6560, M542, M542H, MA860H, 2M542, 2M982, DM542(A), DM860(A) etc. single axis stepper driver controller series. With this 5 axis breakout board, any 1-5 single axis stepper driver controllers can be directly controlled by the PC via the MACH3, EMC2, KCAM4, etc.

All the way to the relay output port, control spindle switch. Output port P17 mouth. RoboticsBD
All the way through the optocoupler isolated 0-10V analog voltage output can be controlled with the corresponding analog interface converter to control the spindle speed. Output port P1 port Open all 17 ports, which can be accessed with the optocoupler drive, 5-axis stepper motor can be controlled. P1 as PWM outputs can be controlled with optocoupler input spindle governor. This can access by a common cathode or common anode input level to 5V drive. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features :

  1. Maximum support 5-axis stepper motor driver controllers
  2. Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
  3. USB power supply and peripherals power phase are separate to protect computer security.
  4. All the signals are to-isolate which can protect your computer security.
  5. 5-input interface to define the Limit, Emergence-Stop, Cutter alignment, etc.
  6. Wide input voltage range: 12-24V, and with anti-reverse function.
  7. One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
  8. Output 0-10V analog voltage for the inverter to control the spindle speed.
  9. All the way to the relay output port, control spindle switch. Output port P17 mouth.
  10. Open all 17 ports, which can be accessed with the optocoupler drive, 5-axis stepper motor can be controlled.
  11. Pin P1 as PWM outputs can be controlled with optocoupler input spindle governor.
  12. Can be accessed by a common cathode or common anode input level to 5V drive. RoboticsBD
  13. All the way through the optocoupler isolated 0-10V analog voltage output can be controlled with the corresponding analog interface converter to control the spindle speed. Output port P1 port. RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Input Power Through PC USB port or 12-24V power supply
Compatible Stepper Motor Driver Max 5, 2-phase Microstep controllers
Driver type Pulse and Direction signal control
Weight (gm) 78
Dimensions (mm) LxWxH 90 x 70 x 20
Cable Length 1.4 meter
Shipment Weight 0.09 kg
Shipment Dimensions 10 × 10 × 40 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1 x MACH3 Interface Board.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

1 x USB to USB Cable(1.2 m)

Product Details
