Arduino Pro Mini 328 5V/16Mhz

RBD-1523

  • Microcontroller: ATmega328P
  • Circuit Operating Voltage: 5V
  • Clock frequency: 16MHz.
  • 6 PWM port: D3, D5, D6, D9, D10, D11.
  • Use For Atmel Atmega328P-AU microcontroller.
  • Support serial download.
  • Support 9V battery.
  • A pair of TTL level serial port transceiver : RX / TX.
BDT 430.00
BDT 430.00 BDT 430.00 BDT 430.00 BDT 430.00
Tax included Tax excluded Tax included Tax excluded
BDT 430.00 Tax excluded
BDT 430.00 Tax included
BDT 0.00 Tax
BDT 430.00 Tax excluded
BDT 0.00 Tax
BDT 430.00 Tax included
Quantity
In-Stock
25 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

This is Pro Mini 5V/16MHz is a 5V Arduino running the 16MHz bootloader. Pro Mini ATMEGA328P come without connectors. We recommend the first time Arduino users start with the Uno R3.

It’s a great board that will get you up and running quickly. The Arduino Pro series is meant for users that understand the limitations of system voltage (5V), lack of connectors, and USB off-board. RoboticsBD

The Pro Mini is a microcontroller board base on the ATmega328P.  It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 6 analog inputs, an on-board resonator, a reset button, and holes for mounting pin headers. RoboticsBD

A six pin header can be connected to an FTDI cable to provide USB power and communication to the board. The Pro Mini Arduino is intended for semi-permanent installation in objects or exhibitions. The pin layout is compatible with the Mini Arduino.  Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

There are two versions of the Pro Mini. One runs at 3.3V and 8 MHz, the other at 5V and 16 MHz. To buy 3.3V/8MHz Pro Mini click on the name below

Features :

  1. ATmega328P running at 16MHz with external resonator (0.5% tolerance)
  2. 0.8mm Thin PCB
  3. USB connection off board
  4. Supports auto-reset
  5. 5V regulator
  6. Max 150mA output
  7. Overcurrent protected
  8. Weighs less than 2 grams!
  9. DC input 5V up to 12V
  10. Onboard Power and Status LEDs
  11. Analog Pins: 8
  12. Digital I/Os: 14
  13. 6 PWM port: D3, D5, D6, D9, D10, D11.
  14. Use For Atmel Atmega328P-AU microcontroller.
  15. Support serial download.
  16. Support 9V battery.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Microcontroller ATmega328
Input Voltage (V) 5
Clock Frequency (MHz) 16
Analog I/O Pins 8
Digital I/O Pins 14
PCB Size ( L x W ) mm 33 x 18
Shipment Weight 0.08 kg
Shipment Dimensions 10 × 5 × 5 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation :

Getting Started with the Arduino Pro Mini

Package Includes :

1 x Arduino Pro Mini 328 China.
