The DJI FPV aircraft delivers powerful propulsion, battery life, and wind resistance, making this system as capable as it is visually stunning. DJI FPV stands out in more ways than one. Sporting front LEDs and aircraft arm lights with customizable-color, DJI FPV allows pilots to make their aircraft as unique as they are. HD video transmission at up to 120fps gives you an ultra-smooth, real-time view of your flight. RoboticsBD
Get the dynamic look of FPV footage easily in S mode. This hybrid flight mode combines the freedom of flying manually with the simplified controls of previous DJI drones. Ideal for new users, N mode offers immersive flight with traditional drone flight controls along with DJI safety features like obstacle sensing. Fly in M mode for complete, limitless control and the full FPV flight experience. Customize parameters and enjoy flight and footage unlike anything else. RoboticsBD
An auxiliary bottom light, Smart Return to Home (RTH), Low Battery RTH, and forward and downward obstacle sensing are all integrated into DJI FPV to help ensure a safe flight, even at high speeds. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The DJI FPV aircraft can record 4K/60fps video at up to 120 Mbps, capturing crisp details that make footage look as exhilarating as the flight.
The DJI O3 (OcuSync 3.0) Transmission System was adapted to match the unique needs of DJI FPV. Enjoy crystal-clear real-time video transmission even at distances of up to 10km
Features:
- Forward Sensing
- Downward Sensing
- ToF Sensor
- Auxiliary Bottom Light
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| Camera |
| Sensor |
1/2.3” CMOS
Effective pixels: 12 million |
| Lens |
FOV: 150°
35mm Format Equivalent: 14.66 mm
Aperture: f/2.8
Focus Mode: Fixed Focus
Focus Range: 0.6 m to ∞ |
| ISO |
100-12800 |
| Shutter Speed |
1/50-1/8000 s |
| Still Photography Modes |
Single shot |
| Max Image Size |
3840×2160 |
| Photo Format |
JPEG |
| Video Resolution |
4K: 3840×2160 at 50/60fps FHD: 1920×1080 at 50/60/100/120fps |
| Video Formats |
MP4/MOV (H.264/MPEG-4 AVC, H.265/HEVC） |
| Max Video Bitrate |
120 Mbps |
| Color Profile |
Standard, D-Cinelike |
| RockSteady EIS |
Available |
| Distortion Correction |
Available |
| Supported File Formats |
exFAT (recommended)
FAT32 |
| Gimbal |
|
| Mechanical Range |
Tilt: -65° to 70° |
| Controllable Range |
Tilt: -50° to 58° |
| Stabilization |
Single-axis (tilt), electronic roll axis |
Max Control Speed
|
60°/s |
| Angular Vibration Range |
±0.01° (N mode) |
| Electronic Roll Axis |
Available |
| Charger |
|
| Input |
100-240 V, 50/60 Hz, 1.8 A |
| Output |
Battery charging interface:
25.2 V ± 0.1 V
3.57 A ± 0.1 A (high current)
1 A ± 0.2 A (low current)
USB Port:
5V/2A (×2) |
| Rated Power |
86 W |
| Intelligent Flight Battery |
|
| Battery Capacity |
2000 mAh |
| Voltage |
22.2 V |
| Max Charging Voltage |
25.2 V |
| Battery Type |
LiPo 6S |
| Energy |
44.4 Wh@0.5C |
| Discharge Rate |
Standard: 10C |
| Weight |
295 g |
| Charging Temperature |
5° to 40° C (41° to 104° F) |
| Max Charging Power |
90 W |
| Aircraft |
|
| Takeoff Weight |
Approx. 795 g |
| Dimensions |
255×312×127 mm (with propellers)
178×232×127 mm (without propellers) |
| Diagonal Distance |
245 mm |
| Max Ascent Speed |
M mode: No limit
S mode: 15 m/s
N mode: 8 m/s |
| Max Descent Speed |
M mode: No limit
S mode: 10 m/s
N mode: 7 m/s |
| Max Speed |
140 kph; M mode: 39 m/s (27 m/s in Mainland China)
S mode: 27 m/s
N mode: 15 m/s |
| Max Acceleration |
0-100 kph: 2 s (in ideal conditions while flying in M mode) |
| Max Service Ceiling Above Sea Level |
6,000 m |
| Max Flight Time |
Approx. 20 mins (measured while flying at 40 kph in windless conditions) |
| Max Hover Time |
Approx. 16 mins (measured when flying in windless conditions) |
| Max Flight Distance |
16.8 km (measured while flying in windless conditions) |
| Max Wind Speed Resistance |
39-49 kph (25-31 mph) |
| Operating Temperature |
-10° to 40° C (14° to 104° F) |
| Transmitter Power (EIRP) |
2.400-2.4835 GHz
FCC: ≤ 31.5dBm
CE: ≤ 20 dBm
SRRC: ≤ 20 dBm
MIC: ≤ 20 dBm
5.725-5.850 Ghz
FCC: ≤ 31.5 dBm
CE: ≤ 14 dBm
SRRC: ≤ 25.5 dBm |
| Number of Antennas |
Four |
| GNSS |
GPS+GLONASS+GALILEO |
| Hovering Accuracy Range |
Vertical:
±0.1 m (with Vision Positioning)
±0.5 m (with GPS positioning)
Horizontal:
±0.3 m (with Vision Positioning)
±1.5 m (with GPS positioning) |
| Supported SD Cards |
microSD (up to 256 GB) |
Internal Storage
|
N/A |
| Shipment Weight |
0.745 kg |
| Shipment Dimensions |
33 × 25 × 24 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
- Datasheet
Package Includes:
1 x DJI FPV Combo.
