This adapter is compatible to handle up to 3A current so applications like toy cars, CCTV Cameras, Routers, Modems, Cordless Phones, Set-Top Boxes, Wireless Devices, and POS Machines are compatible with this adapter.
Compatible with: Raspberry Pi B+, 2, 2B, 2B+,3 ,3B+, Zero, Zero W. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- The adapter is easy to use.
- It comes with a long wire.
- Wide input voltage range (100VAC-280VAC).
- Very low no-load power consumption.
- Very low ripple & noise output for device safety.
- Protections against- under-over voltage/ overload/ short circuit with auto-restart on fault removal.
- Thermal shut down (140°C) with auto-restart on cold condition.
- Soft start & low inrush current.
- Isolation up to 3kv for 5 sec. time period.
- High operating ambient temperature up to 60°C.
- Highly efficient, compact, durable and long life.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Input Voltage (V AC) |
100 ~ 240 |
| Input current (mA) |
100 |
| Output Voltage(V) |
5 |
| Max. Output Current (A) |
3 |
| Output Power(Watt) |
15 |
| Load regulation (%) |
±5 |
| Input Plug |
2-Pin EU type |
| Output Adapter Type (mm) |
Micro USB |
| Connecting cable Length (m) |
1.1 |
| Material |
ABS Plastic |
| Color |
Black |
| Length (mm) |
72 |
| Width (mm) |
46 |
| Height (mm) |
32 |
| Weight (gm) |
105 |
| Shipment Weight |
0.105 kg |
| Shipment Dimensions |
10 × 8 × 7 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x Raspberry Pi Power Adapter with Switch Micro USB.
