P-Channel MOSFET 55V 31A IRF5305 Robotics Bangladesh
  • P-Channel MOSFET 55V 31A IRF5305 Robotics Bangladesh

P-Channel MOSFET 55V 31A IRF5305

RBD-2614

If you've ever wondered how to control the headlight of a car from a microcontroller, a MOSFET is what you need. The IRF5305 is a very common MOSFET with very low on-resistance and a control voltage (aka gate voltage) that is compatible with most 5V microcontroller or mechanical switches. This allows you to control high-power devices with very low-power control mechanisms.

BDT 140.00
BDT 140.00 BDT 140.00 BDT 140.00 BDT 140.00
Tax included Tax excluded Tax included Tax excluded
BDT 140.00 Tax excluded
BDT 140.00 Tax included
BDT 0.00 Tax
BDT 140.00 Tax excluded
BDT 0.00 Tax
BDT 140.00 Tax included
Quantity
140 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

IRF5305 fifth generation HEXFETs utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET Power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications.

Features:-

• Advanced process technology

• Dynamic dv/dt rating

• Fast switching

• Fully avalanche rated

Detailed Specifications:-

Number of Channels 1 Channel
Transistor Polarity P-Channel
Drain-Source Breakdown Voltage (Vds) -55V
Continuous Drain Current (Id) -31A
Drain-Source Resistance (Rds On) 60mOhms
Gate-Source Voltage (Vgs) 20V
Gate Charge (Qg) 63 nC
Operating Temperature Range -55 - 175°C
Power Dissipation (Pd) 110W

Related Documents

pdf.jpg IRF5305 MOSFET Datasheet

Product Details
RBD-2614
140 Items

Specific References

EAN13
2614
