TIP122 Robotics Bangladesh
  • TIP122 Robotics Bangladesh

TIP122

RBD-1445

  • IC Name: TIP122
  • Package/Case: DIP-3
BDT 20.00
BDT 20.00 BDT 20.00 BDT 20.00 BDT 20.00
Tax included Tax excluded Tax included Tax excluded
BDT 20.00 Tax excluded
BDT 20.00 Tax included
BDT 0.00 Tax
BDT 20.00 Tax excluded
BDT 0.00 Tax
BDT 20.00 Tax included
Quantity
In-Stock
14 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

Designed for general−purpose amplifier and low−speed switching applications. This is a TIP122 Power NPN Darlington Transistor which is designed for general purpose amplifier and low speed switching applications. It can generally drive high voltage DC Loads. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. High DC Current Gain −
  2. hFE = 2500 (Typ) @ IC = 4.0 Adc •
  3. Collector−Emitter Sustaining Voltage − @ 100 mAdc
  4. VCEO(sus) = 60 Vdc (Min) − TIP120, TIP125 = 80 Vdc (Min) − TIP121, TIP126 = 100 Vdc (Min) − TIP122, TIP127 •
  5. Low Collector−Emitter Saturation Voltage −
  6. VCE(sat) = 2.0 Vdc (Max) @ IC = 3.0 Adc = 4.0 Vdc (Max) @ IC = 5.0 Adc •
  7. Monolithic Construction with Built−In Base−Emitter Shunt Resistors

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Collector−Emitter Voltage 100
Collector−Base Voltage 100
Emitter−Base Voltage 5
Product Type TIP122 Power NPN Darlington Transistor
Operating Temperature Range (°C) –55° C to +125° C
Mounting Type Through Hole
Shipment Weight 0.005 kg
Shipment Dimensions 3 × 3 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

  1. Datasheet

Package Includes:

1 x TIP122

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-1445
14 Items

Specific References

EAN13
1445
