Male Pin Header 2.54mm Pitch - Blue

Reference RBD-1117

Connects PCBs: Ideal for connecting PCBs (Printed Circuit Boards) with through-hole mounting.
Standard Pitch: 2.54mm pitch ensures compatibility with various components.
Easy Integration: Single row of 40 male pins simplifies assembly.
Durable Construction: Made with high-quality phosphor bronze for reliable connections.

Description
Product Details

Description

This Male Pin Header Single Row is a versatile component designed for connecting printed circuit boards (PCBs) using through-hole mounting. Featuring a standard 2.54mm pitch and a single row of 40 male pins, this header strip offers easy integration and compatibility with various electronic components. The phosphor bronze contact material ensures durability and reliable electrical connections. This male pin header is ideal for a wide range of electronic projects requiring secure PCB connections. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

Through-Hole Mounting: Designed for easy and secure PCB integration.
Standard 2.54mm Pitch: Ensures compatibility with various components.
40 Male Pins: Provides ample connection points for your project needs.
Phosphor Bronze Contacts: Offers reliable and long-lasting electrical connections.
Compact Design: Saves space on your PCB layout.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

PCB Prototyping: Ideal for creating prototypes and testing electronic circuits.
DIY Electronics Projects: Simplifies building and connecting various electronic components.
Breadboard Integration: Allows easy connection of pin headers to breadboards for circuit testing.
Module and Sensor Connections: Provides a reliable way to connect modules and sensors to PCBs.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Connector Type	Male Pin Header
Number of Rows	1
Number of Pins	40
Pitch	2.54mm
Mounting Type	Through-Hole (DIP)
Contact Material	Phosphor Bronze
Contact Resistance	20mΩ
Insulation Material	PBT UL 94V-0
Insulation Resistance	≥1000MΩ
Length	51mm
Width	2mm
Height	7mm
Weight (each)	Approx. 1g
Shipment Weight	0.005 kg
Shipment Dimensions	12 x 8 x 2.5 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1 x Male Pin Header Single Row 2.54mm Pitch - Blue
