Beginners Kit with Arduino Uno R3

This Beginners Kit Arduino Uno R3 is great for absolute beginners. The kit comes with numbered components that would create 15 unique projects from a blinking LED to an RGB light dimmer. RoboticsBD

A good thing about this UNO kit, that is very under-appreciated when it comes to electronics kits — each piece is clearly labeled.

It is never a bad idea to have extra parts like LEDs, jumper wires, resistors around. Beginners can learn the basics of Arduino programming as well as the expert in programming. From this kit, you will get what Arduino is all about and how it is used. RoboticsBD

Whether you are a beginner or already have experience with Arduino under your belt, This Arduino beginners kit by RoboticsBD will be a fun way to expand your knowledge.

Building some creative and simple projects is a great way to walk through coding and basic electronic circuits knowledge.

This kit includes everything you need to get started with electronics using an Arduino and a lot of things that will take you from a beginner to an enthusiast. It includes all of the basics: a UNO board, breadboard, cables, LEDs, resistors, and pushbutton switches.

Great for robot prototyping: Includes Servo motor, LCD module and etc. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Note: 9V Non-Rechargeable Battery is not included in a package, you need to buy it separately.

Features:

1. All-in-one kit, a great starter kit for learning to code.
2. Great for Starting with Arduino Programming
3. A variety of components are included in this pack to try out different projects.
4. UNO Specs:
5. Model Type: UNO Rev R3
6. Microcontroller Chip: ATmega328
7. Input Voltage(Recommended): 7-12V
8. Input Voltage (limit): 6-20V
9. Operating Voltage: 5
10. Analog I/O Pins: 6
11. Digital I/O Pins: 14 (of which 6 provide PWM output)
12. PWM Digital I/O Pins: 6 DC Current per I/O Pin: DC Current per I/O Pin: 40 mA;
13. DC Current for 3.3V Pin: 50 mA
14. Clock Speed: 16 MHz
15. EEPROM: 1 KB (ATmega328)
16. Flash Memory: 32 KB (ATmega328) of which 0.5 KB used by bootloader
17. PWM Output Pins: 6
18. SRAM: 2 KB (ATmega328)
19. Power Supply Option: DC Jack or USB
20. On-Board LEDs: Yes
21. Operating Temperature (°C): -40 to +90
22. Dimensions in mm (LxWxH): 75 x 54 x 12
23. Weight (gm): 26

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

1. Documents, Project are included with the Box.

Package Includes:

1 x JUMPER WIRE 40 PCS SET  (Male to Male)

1 x BREADBOARD (LARGE)

20 x JUMPER WIRE SINGLE MEDIUM (Male to Female)

1 x 10K OHM POTENTIOMETER

1 x BUZZER

1 x 74595 SHIFT REGISTER

1 x IR INFRARED OBSTACLE AVOIDANCE SENSOR

1 x LM35 TEMPERATURE SENSOR / TMP36 TEMPERATURE SENSOR / DS18B20 TEMPERATURE SENSOR MODULE

1 x FLAME SENSOR FIRE DETECTION MODULE /

3 x LIGHT DEPENDING RESISTOR (LDR)

5 x PUSH BUTTON SWITCH

1 x 1 DIGIT 7 SEGMENT LED DISPLAY

1 x 0.56 INCH 4 DIGIT 7 SEGMENT LED DISPLAYS,

1 x DC 5V STEPPER MOTOR + ULN2003 DRIVER BOARD

1 x MINI SERVO SG90

1 x STANDARD LCD 16X2

1 x 9V BATTERY TO 2.1MM FOR ARDUINO UNO

2 x 5 MM RED LED (PACK OF 5)

2 x 5 MM GREEN LED (PACK OF 5)

2 x 5 MM YELLOW LED (PACK OF 5)

1 x KILOOHM (1 KΩ) 1/4W RESISTORS - PACK OF 5

1 x KILOOHM (10 KΩ) 1/4W RESISTORS - PACK OF 5

2 x OHM (220 Ω) 1/4W RESISTORS - PACK OF 5

1 x AA BATTERY HOLDER 2S / 18650 Battery Holder 1s / AA BATTERY HOLDER 1S
