The 15KV High-Frequency DC High Voltage Arc Ignition Generator Inverter Boost Step-Up DIY Kit is an ideal tool for electronics enthusiasts and DIYers. This kit enables the creation of a high-frequency arc generator capable of producing a stable 15KV output, perfect for high school science experiments, negative ion generators, and small-scale scientific projects. The kit includes a PCB board for easy assembly, allowing users to customize and build their own high-voltage step-up transformer circuit. With its compact design and reliable functionality, this kit is a must-have for hobbyists and educational purposes. Please note that this is a DIY kit and requires assembly. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: This item is DIY Kit, not assembled. default with one PCB board.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- High-Frequency Arc Generation: Produces a stable, high-temperature arc for ignition and experimental purposes.
- Adjustable Input Voltage: Operates on 3.7V-4.2V DC with modifications possible for 12V inputs.
- 15KV Output Voltage: Delivers a high-voltage arc with an ignition distance of ≤0.5cm.
- DIY Kit Design: Includes PCB board and components for hands-on assembly and customization.
- Versatile Applications: Ideal for science experiments, electronic research, and plasma ignition.
- Compact and Reliable: Small size (4.2 x 3.2 x 0.16 cm PCB board) with professional circuit layout.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Science Experiments: Perfect for high school and hobbyist experiments involving high-voltage arcs.
- Negative Ion Generators: Can be used in projects requiring high-voltage generation for ionization.
- Plasma Lighter Projects: Produces high-temperature arcs for ignition of combustible materials.
- DIY Electronics: Ideal for enthusiasts building and testing step-up transformer circuits.
- Educational Demonstrations: Great for teaching and demonstrating electrical principles and high-frequency arc generation.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications |
| Input Voltage | 3.7V-4.2V (modifiable for 12V with resistor adjustment) |
| Input Current | ≤2A |
| Output Voltage | ~15KV |
| Output Current | ≤0.4A |
| Ignition Distance | ≤0.5 cm |
| Transformer Structure | Dual primary windings, feedback winding, high-pressure secondary output |
| PCB Board Dimensions | 4.2 x 3.2 x 0.16 cm |
| Applications | Science experiments, negative ion generators, plasma lighters |
| Shipment Weight | 0.025 kg |
| Shipment Dimensions | 8 x 5 x 3 cm |
Please allow 5% measuring deviation due to manual measurement.
