The LM2596HV Power Supply Module – DC/DC and AC/DC is a highly efficient step-down (buck) voltage regulator designed for powering a wide range of electronic circuits and devices. Supporting both AC (5V–30V) and DC (5V–50V) inputs, this module delivers a stable and adjustable DC output between 3.3V and 33V, making it ideal for battery charging, embedded power systems, solar regulation, and DIY robotics applications. Built around the reliable LM2596HV chip, it ensures up to 92% conversion efficiency, minimizing heat generation and power loss. The module also features multiple protection mechanisms—over-current, over-temperature, and short-circuit—to guarantee safe and stable operation. With easy-to-use screw terminals, passive cooling, and a compact mountable PCB, the LM2596HV is an excellent solution for voltage step-down requirements in both industrial and hobbyist environments. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
Dual Input Compatibility: Accepts both AC (5–30V) and DC (5–50V) input sources.
Wide Adjustable Output: Provides regulated DC output from 3.3V to 33V.
High Output Current: Supports up to 3A continuous load with proper heat dissipation.
Energy Efficient: Delivers up to 92% power conversion efficiency.
Reliable Protection: Built-in safeguards against over-temperature, over-current, and short circuits.
Stable Operation: 150kHz switching frequency ensures smooth and noise-free performance.
User-Friendly Terminals: Equipped with screw connectors for quick and secure wiring.
Compact & Mountable: Small PCB (51×26mm) with mounting holes for easy installation.
Passive Cooling Design: Efficient natural heat dissipation—no fan required.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
DIY Electronics Projects: Ideal for powering Arduino, sensors, and microcontrollers.
Battery Charging Systems: Adjustable voltage for lithium or lead-acid batteries.
Solar Power Converters: Used in solar setups for DC voltage regulation.
Automation & Robotics: Provides stable voltage to motors, servos, and controllers.
AC to DC Power Conversion: Converts transformer output AC to regulated DC efficiently.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications |
| Model | LM2596HV |
| Input Voltage (AC) | 5V – 30V |
| Input Voltage (DC) | 5V – 50V |
| Output Voltage | 3.3V – 33V (Adjustable) |
| Output Current | Up to 3A (depends on input voltage & heat dissipation) |
| Output Power | Max 15W |
| Efficiency | Up to 92% |
| Switching Frequency | 150 kHz |
| Protection Features | Over-temperature, Over-current, Short-circuit |
| Cooling Method | Natural convection |
| Mounting | Screw holes for secure attachment |
| Dimensions | 51mm × 26mm |
| Shipment Weight | 0.015 kg |
| Shipment Dimensions | 6 × 3 × 2 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x LM2596HV Power Supply Module - DC/DC and AC/DC Robotics Bangladesh
