Reference: RBD-2298
Banner

PIR Motion Sensor Lamp Holder B22 is a smart lighting accessory designed to convert any standard B22 socket into an automatic motion-activated lighting system. Operating on 100~220V AC, this holder features a built-in 360° infrared motion sensor that automatically turns the connected bulb ON when movement is detected and switches it OFF after a preset delay. Therefore, it significantly reduces energy waste while improving convenience and safety. Additionally, the adjustable delay time (10–240 seconds) and light sensitivity (10–2000 Lux) allow you to customize operation for both night-only or day/night modes. Made from flame-retardant PBT material, this durable and reliable sensor holder is ideal for hallways, staircases, bathrooms, garages, storage rooms, and entryways. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Automatic Motion Detection – Instantly activates lighting when movement is detected within a 360° coverage area.
Adjustable Delay Timer – Customize auto-off time from 10 to 240 seconds to suit your needs.
Day/Night Light Control – Set brightness sensitivity (10–2000 Lux) for night-only or 24-hour operation.
Wide Detection Distance – Covers up to 6 meters, ensuring reliable performance in larger spaces.
Energy Efficient Operation – Prevents unnecessary power consumption by turning lights off automatically.
Simple Installation – Tool-free setup; just insert into a B22 socket and screw in an E27 bulb.
Flame-Retardant Construction – Made from durable PBT material for enhanced safety and longevity.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Home Lighting Automation – Perfect for hallways, staircases, bedrooms, and bathrooms.
Security Lighting – Improves safety in entryways, garages, and basements.
Office & Commercial Spaces – Ideal for warehouses, hotels, and storage areas.
Energy Saving Projects – Reduces electricity bills through smart motion-based activation.
Elderly-Friendly Lighting – Provides automatic illumination without manual switch operation.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Operating Voltage | 100~220V AC |
| Current | 2A |
| Maximum Load Power | ≤ 60W |
| Detection Angle | 360° |
| Detection Distance | ≤ 6m (Optimal at 22~24°C) |
| Delay Time | 10~240 Seconds (Adjustable) |
| Light Sensitivity | 10–2000 Lux (Adjustable) |
| Base Type (Input) | B22 (Pin Type) |
| Bulb Interface (Output) | E27 (Screw Type) |
| Material | PBT (Flame-Retardant Plastic) |
| Color | White |
| Installation | Plug & Play (Tool-Free) |
| Shipment Weight | 0.072 kg |
| Shipment Dimensions | 13 × 6 × 6 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x PIR Infrared Motion Sensor LED Lamp Holder – B22 Base
