The OV7670 Camera Module 30W Pixel is a compact VGA imaging solution designed for embedded vision, robotics, and image processing projects. It features a 300,000-pixel CMOS sensor capable of delivering up to 30 frames per second at 640×480 resolution, ensuring smooth and stable image capture. Because it operates at low power consumption—only 60mW during active VGA operation—it is suitable for portable and battery-powered applications. Moreover, its 67-degree field of view provides a balanced perspective for general-purpose vision systems. With a 1/6-inch optical format and 3.6μm × 3.6μm pixel size, the module offers good light sensitivity and image clarity. The camera communicates via I2C for configuration and parallel data output, making it compatible with microcontrollers such as STM32 and FPGA platforms. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
VGA Resolution Imaging – Captures clear 640×480 images for embedded vision tasks.
30fps Frame Rate – Supports real-time video streaming applications.
Low Power Operation – Consumes only 60mW at 15fps, ideal for portable systems.
Wide Viewing Angle (67°) – Covers a broader scene without large distortion.
High Signal-to-Noise Ratio – 46dB SNR ensures better image clarity.
Good Dynamic Range (52dB) – Preserves detail in varying lighting conditions.
Wide Operating Temperature – Functions reliably from -30°C to +70°C.
Compact Optical Design – Easy integration into robotics and IoT devices.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
Robotic Vision Systems – Enables object detection and navigation tasks.
DIY Surveillance Cameras – Suitable for low-cost monitoring systems.
Embedded Image Processing – Ideal for microcontroller-based vision experiments.
Smart Home Monitoring – Supports small-scale security solutions.
Educational Projects – Useful for learning embedded imaging concepts.
Research and Development – Prototype machine vision systems.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications |
| Model | OV7670 |
| Sensor Type | CMOS Image Sensor |
| Resolution | 640 × 480 (VGA) |
| Pixel Count | 300,000 Pixels (30W) |
| Pixel Size | 3.6μm × 3.6μm |
| Optical Size | 1/6" |
| Viewing Angle | 67° |
| Maximum Frame Rate | 30fps (VGA) |
| IO Voltage | 2.5V – 3.0V |
| Active Power | 60mW at 15fps |
| Dormant Power | <20μA |
| Signal-to-Noise Ratio | 46dB |
| Dynamic Range | 52dB |
| Operating Temperature | -30°C to +70°C |
| Shipment Weight | 0.006 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x OV7670 Camera Module with Connector – 30W Pixel
