| CPU | Model: Rockchip RK3588
Number of Cores: Quad-core ARM Cortex-A76 + Quad Core Cortex-A55
Frequency: Cortex-A76(up to 2.4GHz), Cortex-A55(up to 1.8GHz) |
| GPU | Mali-G610 MP4, compatible with OpenGLES 1.1, 2.0, and 3.2, OpenCL up to 2.2 and Vulkan1.2 |
| VPU | 8K@60fps H.265 and VP9 decoder, 8K@30fps H.264 decoder, 4K@60fps AV1 decoder. 8K@30fps H.264 and H.265 encoder |
| NPU | 6TOPs, supportS INT4/INT8/INT16/FP16 |
| Memory | RAM: 64-bit 4GB/8GB/16GB LPDDR4X@2133MHz |
| Storage | eMMC:0GB/64GB eMMC, at HS400 mode
1 x MicroSD interface, support up to SDR104 mode |
| Connectivity | 1 x On-board PCle 2.5G ethernet controller (RTL8125B) |
| USB | 2 x USB 3.1 Gen1 OTG which combo with DP display(up to 4Kp60)
1 x USB 3.1 Gen1 Host
2 x USB 2.0 Host |
| PCle | up to 4 x PCle interfaces
2 x PCle 2.1 x1 and 2 x PCle 3.0 x2
or 2 x PCle 2.1 x1 and 1 x PCle 3.0 x4
or 1 x PCle 2.1 x1,1 x PCle 3.0 x2, and 2 x PCle 3.0 x1
or 4 x PCle 3.0 x1 |
| Video | HDMI input: 1 x HDMI input, up to 4Kp60
HDMI output:
2 x HDMI outputs which is compatible with HDM2.1, HDM2.0, and HDMl1.4 operation
one support displays up to 7680x4320@60Hz, another one support up to 4Kp60
Support RGB/YUV(up to 10bit) format
MIPI RX:
2 x 4lane MP| DPHY CSl RX which support x4 mode or x2+x2 mode, compatible with MlPI V1.2
2 x 4lane MIPI D/CPHY RX
MIPI TX:
2 x 4-lane MP| D-PHY/C-PHY Combo PHY TX, compatible with MIPI DPHY 2.0 or CPHY 1.1 |
| Codec | On-board ALC5616 Codec
1 x stereo headphone output ( 20mW/CH, THD+N <= -80dB, 160hm Load )
1 x single-end microphone input |
| LED | 1 x SYS LED(Red)
1 x LED1(Green) |
| Others | low power RTC (HYM8563TS) with backup battery input
Support 38Khz IR input
MASK button for eMMC update, reset button, Power button, and recovery mode button
Debug UART,3.3V level, 1500000bps
Working Temperature: 0℃ to 70℃ |
| Connector | 4xDF40C-100DP-0.4V(51), the mating connector is DF40HC(3.0)-100DS-0.4V(51) |
| Power | 5-20VDC input, 20W Max |
