UART EM4100 RFID Card Reader RDM6300

RBD-0915

  • Maximum effective distance up to 150mm
  • Less than 100ms decoding time
  • Support external antenna
  • Uart interface
  • Support EM4100 compatible read-only or read/write tags
  • Small outline design
BDT 415.00
BDT 415.00 BDT 415.00 BDT 415.00 BDT 415.00
Tax included Tax excluded Tax included Tax excluded
BDT 415.00 Tax excluded
BDT 415.00 Tax included
BDT 0.00 Tax
BDT 415.00 Tax excluded
BDT 0.00 Tax
BDT 415.00 Tax included
Quantity
In-Stock
58 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

RDM6300 125KHz EM4100 RFID Card ID Reader Module is designed for reading code from 125KHz card compatible read-only tags and read/write the card. It can be applied in office/home security, personal identification, access control, anti-forgery, interactive toy and production control systems etc. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1.    Maximum effective distance up to 150mm
  2.    Less than 100ms decoding time
  3.    Support external antenna
  4.    Uart interface
  5.    Support EM4100 compatible read-only or read/write tags
  6.    Small outline design

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Operating Frequency 125KHZ
Baud Rate 9600
Interface TTL level RS232 format
Working voltage DC 5V(+/-5%)
Working current <50mA
Receive distance 20~50mm
Working temperature -10°C~+70°C
Storage temperature -20°C~+80°C
Humidity 0~95%
Wiring size: 46*32*3mm
PCB size 38.5 x 20 mm
Weight 7g
Shipment Weight 0.1 kg
Shipment Dimensions 8 × 6 × 4 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

  1.    Interfacing RDM6300 RFID Reader Module with Arduino
  2.    RDM6300 Wiki

Package Includes:

1 x UART EM4100 RFID Card Reader RDM6300
