The 16mm Emergency Stop Push Button - AB6-V is a versatile and reliable switch suitable for various applications. Featuring a mushroom push button design with Snoo Power Button, it ensures immediate halt in critical situations with its emergency stop functionality. With SPST and DPST contact forms, this switch caters to a wide range of control needs, from simple on-off to more complex operations. Constructed with a robust build, including a maximum contact resistance of 50mΩ and minimum insulation resistance of 100MΩ, it delivers consistent and dependable performance. Withstanding temperatures from -25°C to 55°C and featuring a compact design with a φ16mm perforate dimension, this push button switch seamlessly integrates into diverse environments without occupying much space. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Emergency Stop Functionality: Red mushroom head button for immediate stoppage.
- SPST/DPST Contact Options: Selectable contact form for control flexibility.
- Reliable Performance: Low contact resistance (50mΩ max) and high insulation resistance (100MΩ min).
- Wide Operating Temperature: Functional from -25°C to 55°C.
- Compact Design (16mm): Fits well in space-constrained settings.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Industrial Machinery: Emergency stop control for safety in factories and workshops.
- Power Tools: Activation switch for immediate shut-off in case of accidents.
- Safety Systems: Integration into safety circuits for hazard prevention.
- Control Panels: Incorporation into industrial control panels for emergency stop functionality.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Model Number |
AB6-V |
| Head Shape |
Emergency Stop (Mushroom) |
| Contact Rating |
3A @ 250VAC |
| Contact Form |
SPST or DPST (Selectable) |
| Mounting Dimensions |
φ16mm |
| Contact Resistance |
50mΩ Max |
| Insulation Resistance |
100MΩ Min |
| Dielectric Strength |
2000VAC, 50Hz for 1 Min |
| Mechanical Life |
2 x 10^5 Cycles |
| Electrical Life |
5 x 10^4 Cycles |
| IP Degree |
IP40 (Dust-proof) |
| Operating Temperature |
-25°C to 55°C |
| Operating Humidity |
45 to 85% RH, Non-Condensing |
| Shipment Weight |
0.001 kg |
| Shipment Dimensions |
10 x 10 x 6 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
- Ensure proper installation and alignment to prevent malfunctions.
- Avoid exposing the switch to temperatures beyond the specified range.
- Keep the switch away from high humidity environments to prevent damage.
- Check compatibility and electrical requirements before use.
Package Includes:
1 x 16mm Emergency Stop Push Button - AB6-V
