JGY370 Motors are permanent magnet motors known for delivering high power in a compact, portable package. JGY-370 DC motors Ideal for applications requiring motor speed adjustment and reversing capabilities.
In most cases, the addition of a gearbox is intended to limit the speed of the motor's shaft and increase the motor's ability to output torque. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- DC motor with 12V operating voltage.
- Self-locking mechanism to prevent backdriving.
- Reduction worm gear for high torque output.
- Low noise and stable performance.
- Compact size for easy integration into systems.
- Durable construction for use in harsh environments.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Robotics and automation.
- Solar tracking systems.
- Medical equipment and devices.
- Electric curtains and blinds.
- Automatic door and gate systems.
- Automotive and marine applications.
- DIY projects and hobbies.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Model |
JGY-370 |
| Motor Voltage |
12V |
| No-load Speed |
160rpm |
| No-load Current |
35mA |
| Load Speed |
128rpm |
| Load Current |
180mA |
| Stall Torque |
2.2kg.cm |
| Load Torque |
0.55kg.cm |
| Size |
8 x 3.5 x 3.0 cm |
| Shipment Weight |
0.155 kg |
| Shipment Dimensions |
12 × 8 × 4 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
Note:
- When you use a motor, can not have bound items, such as adhesives that do not flow into the rotary shaft through bearings, obstructing the operation of the motor.
- The rod of rotation of the motor's life may have the opposite effect, in order to prolong life, please check whether your load goods according to regulations, can not overload or prejudice the rotation shaft hanging items.
- Manufactured heavy eccentric load of radiation, harmful life of the motor.
- Do not store it than four weeks high or in extreme humidity, but also do not place it in the etching gas, the motor will reduce the effect.
- Do not run the motor in the surrounding temperature and moisture.
Package Includes:
1 x JGY-370 DC 12V 160RPM Self-locking Reduction Worm Gear Motor
