Cap Conductive Slip Ring 4 Wire Robotics Bangladesh
  • Cap Conductive Slip Ring 4 Wire Robotics Bangladesh

Cap Conductive Slip Ring 4 Wire

RBD-1388

  • A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.

    Wire Size: AWG28# Silver Plated Teflon UL
  • Wire Length: 250mm (rotor), 250mm (stator)
BDT 790.00
BDT 790.00 BDT 790.00 BDT 790.00 BDT 790.00
Tax included Tax excluded Tax included Tax excluded
BDT 790.00 Tax excluded
BDT 790.00 Tax included
BDT 0.00 Tax
BDT 790.00 Tax excluded
BDT 0.00 Tax
BDT 790.00 Tax included
Quantity
In-Stock
19 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure. A slip ring can be used in any electromechanical system that requires rotation while transmitting power or signals. It can improve mechanical performance, simplify system operation and eliminate damage-prone wires dangling from movable joints.

Also called rotary electrical interfaces, rotating electrical connectors, collectors, swivels, or electrical rotary joints, these rings are commonly found in slip ring motors, electrical generators for alternating current (AC) systems and alternators and in packaging machinery, cable reels, and wind turbines. They can be used on any rotating object to transfer power, control circuits, or analog or digital signals including data such as those found on aerodrome beacons, rotating tanks, power shovels, radio telescopes, telemetry systems, heliostats or ferris wheels.

A slip ring (in electrical engineering terms) is a method of making an electrical connection through a rotating assembly. Formally, it is an electric transmission device that allows energy flow between two electrical rotating parts, such as in a motor.  Featured By RoboticsBD. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. Electrical test equipment
  2. Indexing tables
  3. Mini cable reels
  4. CCTV pan/tilt camera mounts
  5. Aviation, military, instrument, medical equipment.
  6. Min-type wire-rolling machine
  7. Closed-circuit control
  8. Laboratory equipment

Features:

  1. Wire Size: AWG28# Silver Plated Teflon UL
  2. Wire Length: 250mm (rotor), 250mm (stator)
  3. Contact: Gold to gold
  4. Working Temperature: -20~+60℃
  5. Protection Level: IP54
  6. Life: 50 million turns (depends on specific working speed and environment)

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Voltage: 240 VAC/DC
Current: 2A per circuits
Speed: 0-300 Rpm
Circuits: 4
Housing Material: Engineering Plastics
Work Humidity: 60%RH or higher
Work Temp.: -40 Degree ~+60 Degree
Contact material: Gold plated ring Gold plated brush
Insulation resistance: 1000
Shipment Weight 0.032 kg
Shipment Dimensions 10 × 10 × 6 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1 x Capsule Slip Ring 4 Wire
