This 1.3″ I2C OLED Display is an OLED monochrome 128×64 dot matrix display module with I2C Interface. It is perfect when you need an ultra-small display. Comparing to LCD, OLED screens are way more competitive, which has a number of advantages such as high brightness, self-emission, high contrast ratio, slim outline, wide viewing angle, wide temperature range, and low power consumption. It is compatible with any 3.3V-5V microcontroller, such as Arduino.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: Product images/ Components brand may vary from actual product as our stock rotates.
Pin Definition:
1.GND: Power ground
2.VCC: Power positive
3.SCL: Clock wire
4.SDA: Data wire.
Features:
- Only Need 2 I/O Port to Control
- Resolution : 128×48 pixels
- Color: White
- Fully Compatible with Arduino
- Working temperature: -30°C ~ 70°C
- Factory configured for SPI protocol (can be easily changed to IIC)
| General Specification |
| Display Size | 1.3 inch |
| Resolution | 128 x 64 Pixels |
| Controlling Chip | SSH1106 |
| Display Area | 34.5 x 19mm |
| Driving Voltage | 3.3-5V |
| Operating Temperature | -40º~70º Celsius |
| Interface Type | IIC |
| Pixel Color | White |
| Length (mm) | 35.5 |
| Width (mm) | 33.5 |
| Height (mm) | 4 |
| Weight (gm) | 7 |
| Shipment Weight | 0.01 kg |
| Shipment Dimensions | 8 × 6 × 2 cm |
Please allow 5% measuring deviation due to manual measurement.
Documentation:
- SPI/I2C Library for Arduino
- GFX Library for Arduino
Package Includes:
1 x 1.3 Inch I2C OLED Display Module 4pin- White
