GPS Module NEO-6M Satellite Positioning Module for Arduino with MicroUSB

Reference RBD-2397

High-Precision GPS Module: NEO-6M satellite positioning module with MicroUSB interface for easy setup.
USB and TTL Interface: Supports debugging through MicroUSB or external TTL serial connection.
Built-in Ceramic Antenna: Provides reliable satellite signal reception; SMA interface supports active antennas.
Wide Voltage Compatibility: Operates on 3.3V-5V systems, ideal for Arduino, STM32, and other microcontrollers.
Customizable Output Settings: Adjustable baud rate and output frequency using U-CENTER software.
Compact and Lightweight: Small form factor (39 x 25.5 mm) for seamless integration into projects.

Description
Product Details

Description

The NEO-6M GPS Module is a reliable and compact satellite positioning module designed for seamless integration with Arduino, STM32, and other microcontroller systems. Featuring a MicroUSB interface for easy debugging and a TTL interface for direct control, this module offers flexible connectivity options. The built-in ceramic antenna ensures excellent satellite signal reception, while the SMA interface allows for an external active antenna connection. Operating at 3.3V-5V, it is compatible with most development platforms. Customizable baud rate and output frequency through U-CENTER software make this module adaptable to a wide range of applications, including navigation, tracking, and time synchronization. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

MicroUSB Interface: Debug easily with standard phone cables, no additional tools required.
Built-in Ceramic Antenna: Ensures reliable GPS satellite acquisition and tracking.
SMA Antenna Support: Connect an active external antenna for enhanced performance.
Wide Compatibility: Works with 3.3V-5V systems like Arduino and STM32.
Customizable Settings: Adjust baud rate and output frequency via U-CENTER software.
Precise Timing Support: PPS signal provides nanosecond-level timing accuracy.
Compact Design: Small size (39 x 25.5 mm) for easy integration in space-constrained projects.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

Arduino GPS Projects: Seamlessly integrate GPS capabilities into Arduino-based systems.
Microcontroller Development: Use with STM32 and other platforms for accurate positioning.
Vehicle Navigation: Build GPS-based tracking and navigation solutions for vehicles.
Robotic Systems: Enable precise positioning and navigation for robots.
Geographic Data Logging: Record location data for research and environmental monitoring.
High-Accuracy Timing: Utilize the PPS clock signal for synchronization in precision applications.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specifications
Model	NEO-6M
Operating Voltage	3.3V-5.0V
Current Consumption	40mA
Default Baud Rate	9600 (adjustable via U-CENTER)
Output Frequency	1Hz (adjustable via U-CENTER)
Built-in Antenna	Ceramic
External Antenna Interface	SMA
Pin Definitions	VCC, GND, TXD, RXD, PPS
Frequency	1575.42 MHz
Dimensions	39 x 25.5 mm
Shipment Weight	0.018 kg
Shipment Dimensions	6 x 3 x 2 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

GPS second pulse signal PPS one second, it is used to indicate the role of the whole second moment, and the time is usually marked with the rising edge of PPS seconds pulse. Because GPS can give UTC time, but received the user is there will be a delay, then in order to get the precise timing, the introduction of PPS signal rising edge to indicate the UTC whole seconds in time, the accuracy can be to a nanosecond, and no accumulated error.

Pin definition:

1, VCC: power supply (3.3V-5V)

2, GND: ground wire

3, TXD: module serial port to send pin (TTL level, can not be directly connected to the RS232 level, can be connected to the microcontroller RXD)

4, RXD: module serial port receive pin (TTL level, can not be directly connected to the RS232 level, can be connected to the microcontroller TXD)

5, PPS: clock pulse output pin.

Package Includes:

1 x GPS Module NEO-6M Satellite Positioning Module for Arduino with MicroUSB
