LM2577 3A DC-DC Step UP LED Voltmeter 3-34 to 4-35V Adjustable Boost Converter Module Robotics Bangladesh
  • LM2577 3A DC-DC Step UP LED Voltmeter 3-34 to 4-35V Adjustable Boost Converter Module Robotics Bangladesh

LM2577 3A DC-DC Step UP LED Voltmeter 3-34 to 4-35V Adjustable Boost Converter Module

RBD-1915

  • Input voltage range : 3-34V DC
  • Output voltage range : 4-35v DC adjustable
  • Output current:3A
  • Voltmeter range:0 to 40V,error +-0.1v
  • Multiple output regulator.
  • One button to switch input and output voltage display.
  • Power-down memory function.
  • Press the button for 3 seconds can turn OFF/ON the LED display.
BDT 440.00
BDT 440.00 BDT 440.00 BDT 440.00 BDT 440.00
Tax included Tax excluded Tax included Tax excluded
BDT 440.00 Tax excluded
BDT 440.00 Tax included
BDT 0.00 Tax
BDT 440.00 Tax excluded
BDT 0.00 Tax
BDT 440.00 Tax included
Quantity
In-Stock
28 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

The LM2577 3A DC-DC Step UP LED Voltmeter 3-34 to 4-35V Adjustable Boost Converter module is a 150 KHz fixed frequency PWM buck (step-down) DC/DC module. Requiring a minimum number of external components, these regulators are cost-effective, and simple to use.

This version of LM2577 DC-DC step-up (boost) power supply module includes the very useful addition of an integrated digital voltage meter.

Together with its high precision multi-turn potentiometer, this means any desired output voltage within its supply range can be set without the need for an external voltage meter. The module also boasts a very high operating range with a DC input supply range of 3 – 34V and an adjustable output range of 4 – 35V. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features :

  1. Multiple output regulator.
  2. One button to switch input and output voltage display.
  3. Power-down memory function.
  4. Press the button for 3 seconds can turn OFF/ON the LED display.
  5. With wiring terminal.
  6. When adjusting the blue potentiometer, please use a multimeter to monitor the voltage
  7. Rotating Clockwise can raise the voltage while rotating  counterclockwise could lower the voltage
  8. When the module output voltage cannot be adjusted ( the output voltage is always equal to the input voltage ) Please adjust the potentiometer counterclockwise 20 laps (20 turns) or more till it works.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Input Voltage (V) 3 to 34
Output Voltage(V) 4 ~ 35
Max. Output Current (A) 3
Voltmeter Range(V) 0 to 40
Switching Frequency(KHz) 52
Operating Temperature (°C) -40 to 90
Length (mm) 60
Width (mm) 35
Height (mm) 13.5
Weight (gm) 24
Shipment Weight 0.027 kg
Shipment Dimensions 7 × 4.5 × 2 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes :

1 x LM2577 3A DC-DC Step UP Voltmeter.
