Mercury Medallion Module

RBD-2089

  • Consists of a mercury switch
  • 680Ω resistor
  • LED that will light up when tilt is detected.
BDT 69.00
BDT 69.00 BDT 69.00 BDT 69.00 BDT 69.00
Tax included Tax excluded Tax included Tax excluded
BDT 69.00 Tax excluded
BDT 69.00 Tax included
BDT 0.00 Tax
BDT 69.00 Tax excluded
BDT 0.00 Tax
BDT 69.00 Tax included
Quantity
In-Stock
75 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

This module consists of a mercury switch, a 680Ω resistor and a LED that will light up when tilt is detected. The mercury ball will open/close the circuit when the module is rotated.  Featured By RoboticsBD.

Mercury switch module and digital 13 interface comes with LED to build a simple circuit, the production of tilt lights with the digital 13 interfaces comes with the LED, the mercury tilt switch sensor access to digital 3 interfaces, when the mercury
tilt switch sensor has a button signal, LED light, and vice versa.  Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

Note: Product images/ Components brand may vary from actual product as our stock rotates.

Note: PCB might be different from the picture as per stock

Connection Diagram:

General Specification
Operating Voltage 3.3V to 5.5V
Length (mm) 22
Width (mm) 24
Height (mm) 25
Weight (gm) 2
Shipment Weight 0.005 kg
Shipment Dimensions 12 × 8 × 2.5 cm

Please allow 5% measuring deviation due to manual measurement.

Package Includes:

1 x Mercury Medallion Module

Product Details
RBD-2089
75 Items

Specific References

EAN13
2089
Comments (0)
Grade
No customer reviews for the moment.
