Dust Sensor For Arduino
  • Dust Sensor For Arduino
  • Dust Sensor For Arduino
  • Dust Sensor For Arduino
  • Dust Sensor For Arduino

Dust Sensor For Arduino

RBD-0338
Waveshare

  • Sharp GP2Y1010AU0F onboard,
  • Detecting fine particle larger than 0.8μm
  • Low power consumption
  • Analog voltage output
  • The output level is linear with dust density

Check out New Product

Optical Dust Sensor- GP2Y1010AU0F

BDT 890.00
BDT 890.00 BDT 890.00 BDT 890.00 BDT 890.00
Tax included Tax excluded Tax included Tax excluded
BDT 890.00 Tax excluded
BDT 890.00 Tax included
BDT 0.00 Tax
BDT 890.00 Tax excluded
BDT 0.00 Tax
BDT 890.00 Tax included
Quantity
Out-of-Stock

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

Dust Sensor, A simple Air Monitor

Featured By RoboticsBD.

(Retired) This product has been retired from our catalog and is no longer for sale. This page is made available for those looking for datasheets and the simply curious.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. Sharp GP2Y1010AU0F onboard, detecting fine particle larger than 0.8μm in diameter, even like the cigarette smoke
  2. Low power consumption, analog voltage output, the output level is linear with dust density
  3. Embedded voltage boost circuit to support wide range of power supply

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD Robotics

Applications:

  1. Air purifier
  2. Air conditioner
  3. Air monitor
  4. PM2.5 Detector

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD Robotics

Pin Description:

In the case of working with a MCU:

  1. VCC ↔ 2.5V ~ 5.0V
  2. GND ↔ GND
  3. AOUT ↔ MCU.IO (analog output)
  4. ILED ↔ MCU.IO (module driving pin)

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD Robotics

General Specification
Sensitivity : 0.5V/(100μg/m3)
Measurement range : 500μg/m3
Power : 2.5V~5.5V
Operating current : 20mA(max)
Operating temperature : -10℃~65℃
Storage temperature : -20℃~80℃
Life time : 5 years
Dimension : 63.2mm×41.3mm×21.1mm
Mounting holes size : 2.0mm
Air hole size : 9.0mm
Shipment Weight 0.045 kg
Shipment Dimensions 6 × 5 × 5 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD Robotics

Package Includes:

1 x Dust Sensor For Arduino

Product Details
RBD-0338

Specific References

EAN13
0338
