MST 10RL-R01-03-100

Reference RBD-1630

MST 10RL-R01-03-100
Temperature Transmitter
IN:PT100 OUT:4-20mA

BDT 8,000.00

BDT 8,000.00 BDT 8,000.00 BDT 8,000.00 BDT 8,000.00

Tax included Tax excluded Tax included Tax excluded

BDT 8,000.00 Tax excluded

BDT 8,000.00 Tax included

BDT 0.00 Tax

BDT 8,000.00 Tax excluded

BDT 0.00 Tax

BDT 8,000.00 Tax included

Quantity

In-Stock

In stock: 41 Items

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Description
Product Details

Description

Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

Free programmable via PC-Software
Option with eHART -Protocol
Communication through Supply loop 4…20mA

Other Details:

Linearised temperature measurement
With Pt100 3-wire sensor
Low price simple operation
Free programmable via PC-Software
Option with eHART -Protocol
Communication through Supply loop 4…20mA
Using a standard HART -Modem. RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Brand:	MST
Model:	MST10RL
Type:	pt100
Measurement ranges:	-200 to 850°C
Min. measurement Ranges:	10K
Connection type:	3-wire connection
Sensor current:	0.5mA
Output signal:	4 to 20mA
Signal on alarm: Understanding:	Linear drop to 3.8mA
Overranging:	Linear rise to 20.5mA
Sensor break, seneor open-circuit:	3.6mA or 22mA.
Dimensions:	44 mmX22.5 mm
Weight:	Approx. 34g
Materials: Housing:	PC / Potting: epoxy
Shipment Weight	0.350 kg
Shipment Dimensions	10 × 10 × 6 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Specification:

Input: RTD Type pt100
Accuracy: 0.2K or 0.1% of span
Performance – characteristics
Response time: 1s
Calibration temperature :+23°C(73.4K)±5K
Long term stability: ≤0.05% year Switch on delay: ≤5s
Influence of ambient: Negligible Load influence: Negligible
Power supply influence: Negligible
Resolution: 1μA
Ambient temperature limits: 40 to +85 °C (-40 to 185 °F)
Storage temperature: -40 to +100 °C (-40 to 212 °F)
Condensation: Allowable
Degree of protection: IP00/IP66 installed
Communication through Supply loop 4…20mA using a standard HART -Modem
Electromagnetic compatibility (EMC): Interference immunity and interference emission according
GB/T17626.2-1998), compliance with IEC 61000-4-3: 1995

Package Includes:

1 x MST 10RL-R01-03-100
