This Momentary Tactile Push Button Module DC 5V 12V Switch is ideally suited to add a button to your projects and gives a high signal when it is pressed.
The module of the push button is a fully-fledged device with which you can install it immediately in the project, without using a pull-up or tightening resistances, because this is already in the circuit. The button together with the resistor is located on the board, where there are holes for installation. The built-in resistor has a rating of 10 kΩ.
The module is designed for two contacts: when pressed, they are closed and open when released. There are also 3 outputs on the board: I, S, + 5V. Contact I is connected to the common wire of the circuit, S is the output of the module and + 5V is connected to the power supply.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: Product images/ Components brand may vary from actual product as our stock rotates.
Note: PCB might be different from the picture as per stock
| General Specification |
| Operating Voltage (VDC) | 5 |
| Contact Resistance | ≤50 MΩ |
| Operating Temperature Range (°C) | -25 to 105 |
| Mech. & Electrical Lifecycle | ≈ 100,000 |
| PCB thickness | 1.5 mm |
| Length (mm) | 20 |
| Width (mm) | 16 |
| Height (mm) | 7 |
| Weight (gm) | 1 (approx.) |
| Shipment Weight | 0.01 kg |
| Shipment Dimensions | 12 × 8 × 2.5 cm |
Please allow 5% measuring deviation due to manual measurement.
Package Includes:
1 x Momentary Tactile Push Button Module DC 5V 12V Switch
