Arduino Micro R3

The Micro is a microcontroller Arduino Micro No Headers board based on the ATmega32U4, developed in conjunction with Adafruit. It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a micro USB cable to get started. It has a form factor that enables it to be easily placed on a breadboard.

This Arduino Micro is similar to the Arduino Leonardo in that the ATmega32U4 has built-in USB communication, eliminating the need for a secondary processor. This allows the Micro to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behavior of the board.

Onboard is the processor, crystal, micro USB connection with fuse, Reset button, ISP low-level reprogramming header, ON LED, TX and RX LEDs, an extra user pin #13 LED, and a 3.3V regulator. You’ll probably also want to pick up a micro-B USB cable to connect this board to your computer

You can use it for basic Arduino sketches as well as USB client projects like making it appear as a mouse or keyboard to your computer! Although it is not shield compatible – it does have all the same pins as a Leonardo. Its best for when you want to shrink your project down or use it on a breadboard. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

1. Microcontroller: The Arduino Micro R3 is based on the ATmega32U4 microcontroller, which provides a 32-bit processing power and a wide range of features.

2. USB Interface: The board features a Micro-USB interface, which allows it to be easily connected to a computer or other USB devices.

3. Digital I/O Pins: The Arduino Micro R3 has 20 digital input/output pins, including 7 pins that can be used as PWM outputs, providing a wide range of connectivity options.

4. Analog Inputs: The board also has 12 analog inputs, which provide a high resolution of conversion for analog signals.

5. Compatible with Arduino IDE: The Arduino Micro R3 is fully compatible with the popular Arduino Integrated Development Environment (IDE), making it easy for users to write and upload code to the board.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

1. Robotics: The small size and powerful features of the Arduino Micro R3 make it a popular choice for building small robots and controlling various actuators and sensors.

2. Home Automation: The board can be used to build home automation systems, such as controlling lights, fans, and other household appliances.

3. Musical Instruments: The PWM outputs and analog inputs on the Arduino Micro R3 make it ideal for building custom electronic musical instruments and sound effects generators.

4. Wearable Devices: Due to its compact size and low power consumption, the Arduino Micro R3 is commonly used in the development of wearable devices and e-textiles.

5. Internet of Things (IoT): The board can be used as a building block for IoT projects, such as connecting sensors and actuators to the Internet for remote monitoring and control.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

1. ATMEGA32U4 DATASHEET
2. SCHEMATIC
3. EAGLE FILES

Package Includes:

1 x Arduino Micro R3 (China)
