Quad-band Cellular Antenna SMA 7.75inch - Male

RBD-2784

  • Supports GSM, DCS, and PCS bands (824MHz to 1990MHz) for compatibility with most cellular networks.
  • Built to withstand harsh environments with a brass body, brass contact, and a weatherproof insulator.
  • Features a standard SMA connector for simple connection to your cellular device.
  • 7.75-inch size makes it ideal for portable applications or discreet placement.
BDT 299.00
BDT 299.00 BDT 299.00 BDT 299.00 BDT 299.00
Tax included Tax excluded Tax included Tax excluded
BDT 299.00 Tax excluded
BDT 299.00 Tax included
BDT 0.00 Tax
BDT 299.00 Tax excluded
BDT 0.00 Tax
BDT 299.00 Tax included
Quantity
In-Stock
19 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

The Quad-band Cellular Antenna SMA 7.75 inch is a powerful solution for improving cellular reception in areas with weak signal strength. This high-gain antenna operates on GSM, DCS, and PCS bands (824MHz to 1990MHz), making it compatible with most cellular networks. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. High Gain Performance: Effectively amplifies cellular signals for stronger connections.
  2. Wideband Compatibility: Supports GSM, DCS, and PCS cellular bands for broad network coverage.
  3. Durable Design: Built to last with high-quality materials and construction that meets military standards for environmental resistance.
  4. Standard SMA Connector: Ensures easy installation with various cellular devices.
  5. Compact Size: 7.75-inch form factor for convenient placement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. Automatic Vehicle Location (AVL): Enhances cellular signal strength for reliable tracking and communication in fleet management systems.
  2. Remote Data Acquisition: Maintains stable cellular connection for data transmission from remote locations.
  3. Cellular Signal Boosting: Improves cellular reception in rural areas, buildings, or weak signal zones.
  4. Industrial IoT Applications: Strengthens cellular connectivity for reliable data transfer in industrial settings.
  5. Public Safety: Ensures clear communication for emergency personnel in remote locations.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Connector SMA
Impedance 50 Ohm
Frequency Range GSM/850E: 824-894MHz, GSM: 880-960MHz, DCS: 1710-1880MHz, PCS: 1850-1990MHz
V.S.W.R. ≤ 1.5 (0-6 GHz)
Operating Temperature -65°C to +165°C
Durability (Mating Cycles) ≥ 500 Cycles
Material Body: Brass, Contact: Brass, Insulator: Teflon or Delrin
Shipment Weight 0.015 kg
Shipment Dimensions 20 x 7 x 7 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

  1. Datasheet

Package Includes:

1 x Quad-band Cellular Antenna SMA 7.75inch

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-2784
19 Items

Specific References

EAN13
2784
