Works with Amazon Alexa, Google Assistant, Siri(iOS 12.0 or later), Tmall Genie, Tecent Xiaowei, DingDong, Rokid, DuerOS, etc.
Why choose this product?
Say goodbye to use remote controls for each of the IR home appliances such as TV, Air-Conditioner , TV box, light, Fan, Audio, etc. You can remotely control these devices with the tap of your finger on the mobile App, anytime and anywhere.
Please kindly read the user manual carefully before usage and keep it for future reference. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
All in One Smart Remote Control
With this Universal IR Remote Control, you may use your smart phone to control home appliances, such as STB(Set-Top-Box), TV Box, TV, Air Conditioner, Fan, DVD, etc. It's compatible with most of brands in the market.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
App Remote Control
Turn on your air conditioner, no matter where you are.
-Support 99% air conditioner in the market, automatic cloud panel match, one button download App to remote control
-Turn on AC in advance, enjoy the warm time when you get home
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Works with Amazon Alexa, Google Assistant
By connecting App to Amazon Alexa, Google Home, you are able to control your home appliances by voice. For example:
-Alexa, turn on the TV;
-OK Google, set air conditioning temperature to 25 degrees.
Timer and Automatic Trigger
Never miss one second of excellent match
-Stay up late for the match, but always oversleep?
-The smart remote control helps you turn on TV at right time and right channel. Enjoy your match!
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
IR Learning Function:
-Customizing buttons in the Tuya Smart App
If your home appliances is not in the brand list or not supported, you may use this function to copy the key function of original remote control to App.
NOTE: DIY does not support voice control
Wide IR Remote Control Range
Control the infrared home appliances within 10 Meters in one room, can be used in most of living rooms and bedrooms with wide range,fulfill requirements of most families.
NOTE:
IR can not penetrate walls, so make sure there is no obstacle between IR remote and the IR devices. So,If you want to control household appliances in different rooms, you need to install one in each room
Share the universal remote control with your family
Control the infrared home appliances with your family together. Have fun to enjoy smart life.
Automation in App
By creating "Automation" in App and interworking with other Tuya smart home devices, the universal remote control is able to execute actions automatically according to conditions, such as device status, weather and time. Please note: The door sensor,temperature sensor and motion sensor are not included in the package.
360° Petal Shape IR Emitting Lamp
Multi-directional launch, guarantee that every order will be served quickly and accurately.
Every components and parts are from the top manufacturer.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Input |
DC 5V/1A(Micro USB NO Adapter) |
| Infrared Frequency |
38KHz |
| IR Remote Control Distance |
10m |
| Connection |
Wi-Fi 2.4GHz |
| App |
TuyaSmart or Smart Life |
| Temperature Measurement Range |
0℃-80℃ |
| Temperature Accuracy |
±1℃ |
| Humidity Measurement Range |
0%RH-99%RH |
| Humidity Accuracy |
±5%RH |
| Material |
ABS |
| Size |
75mm x 19.7mm |
| Shipment Weight |
0.005 kg |
| Shipment Dimensions |
3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
How to download APP
Please Open your app store, search for "Tuya smart " or "Smart Life" and install it. Or You can aslo scan the QR code below to download.
What does the app page look like
App may be modified to better. Here is just a reference
How to build an automated process
Take the temperature adjustment setting air conditioning setting as an example.
- Select the "+" button on the "Smart" page to establish an automated process
- Select "when device status changes". (You can also choose other conditions according to your actual needs)
- Select the devices as the condition. (Here takes the temperature and humidity remote control equipment as an example)
- Select the state condition of the device, and choose the temperature as the input condition.
- Set the temperature conditions. There can be "greater than"/"less than"/"equal to", set the temperature value below. Then select the "Next" button.
- Set the task to run after the conditions are met. Here, select the device that needs to be run.
- Choose to run the air conditioner. You can choose the devices you want to run according to the actual situation.
- Set the command when operating the air conditioner.
- "Smart" condition and operation summary page, select "Save".
- The establishment of the automation process is complete. You can quickly close and open the automation on this page.
FQA
1.What devices can control with Wi-Fi IR Remote control?
You can control TV, Fan, Air conditioner and other IR enabled appliances.
2. What should I do when I cannot control the devices with this remote control?
Firstly, make sure your mobile device and the Wi-Fi IR Remote control are adjacent and connected to the same network, Assure the Wi-Fi infrared remote control is always power on.
3. Can I control devices through 2G/3G/4G network?
The Wi-Fi IR Remote control and mobile device are required to share the same Wi-Fi network when adding Wi-Fi IR Remote Control the first time. After device configuration succeed, you can remotely control devices through 2G/3G/4G/5G cellular network.
4.What should I do when device configuration process has failed ?
you can:
Check whether the remote control is powered on or not.
1).Check whether your mobile device is connected to2.4GHz Wi-Fi network.
2).Check your network connectivity, make sure the router is working properly.
3).Make sure the Wi-Fi password entered is correct when adding remote control.
5. Can it go through walls or be used to control IR devices in upstairs/downstairs rooms?
IR can not go through walls, so make sure there are no obstacles between IR remote and IR enabled devices.
6. We have Huawei/Xiaomi set-top box, why is it not connecting?
There are two types of set-top boxes, OTT and IPTV, the most obvious difference is that IPTV supports living streaming while OTT does not. please make sure you have matching TV box before setup.
7.What we should do when we are unable to use IR remote to control an electric device?
Please check the following:
1).IR remote network in good condition(click any key on the remote control panel in the app and see whether the indicator light starts flashing. if it flashes, it indicates to work properly.
2).There is no object blocking between IR remote and electric device
3).The factory remote control of electric device is IR enabled.(cover the top of the remote control with hand or any object, then press any keys. if the device does not respond, it is IR based, otherwise, it is Bluetooth or RF based remote control.)
Package Includes:
1 x Universal IR Remote Control
1 x Micro Charging Cable (NO ADAPTER)
1 x Adhesive Pad
1 x User Manual
Gallery (Real Shot)
