Ardumoto Shield L298P Motor Driver Robotics Bangladesh
  • Ardumoto Shield L298P Motor Driver Robotics Bangladesh
  • Ardumoto Shield L298P Motor Driver

Ardumoto Shield L298P Motor Driver

RBD-0392

  • L298P based Arduino motor driver shield
  • Forward, Backward steering indicators
  • Can Drive 2 DC Motors
  • Up to 2A of Maximum Current. RoboticsBD
BDT 699.00
BDT 699.00 BDT 699.00 BDT 699.00 BDT 699.00
Tax included Tax excluded Tax included Tax excluded
BDT 699.00 Tax excluded
BDT 699.00 Tax included
BDT 0.00 Tax
BDT 699.00 Tax excluded
BDT 0.00 Tax
BDT 699.00 Tax included
Quantity
In-Stock
13 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

This is a motor shield for Arduino that can control two DC motors. Based on the L298P, the motor driver shield can drive up to 2 amps per channel. The board takes its power from the same Vin line as the Arduino board, includes blue and yellow LEDs to indicate active direction, and all driver lines are diode protected from back EMF. The new version of this shield allows for either 3.3 or 5v logic, a separate and more robust VIN connection, and the PWM input has moved to pin 3. Control for motor attached to OUT1/2 is connected to digital line 12 (direction A) and digital line 3 (PWM A). Control for motor attached to OUT3/4 is connected to digital line 13 (direction B) and digital line 11 (PWM B). Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. A convenient motor interface can be divided into two motor outputs. RoboticsBD
  2. Forward and Backward steering are indicators.
  3. Extra Soldering Points for Prototyping.
  4. Maximum Supply Voltage: 18V

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Logic Part Input Voltage 5VDC
Drive Part of the Input Voltage 6.5 ~ 12VDC
Drive Part of the Operating Current 2A
Maximum Dissipation Power 25W
Length (mm) 57
Width (mm) 53
Height (mm) 13
Weight (gm) 19
Shipment Weight 0.022 kg
Shipment Dimensions 7 × 5 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1  x Ardumoto Shield L298P Motor Driver.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-0392
13 Items

Specific References

EAN13
0392
