TD-8120MG Digital High Torque Servo Motor Metal Gear 20kg 360° Continuous Rotation

Reference RBD-3230

TD-8120MG 360° Continuous Rotation Digital Servo with 22.8kg.cm torque.
Provides speed-based motion control for wheels, arms, and automation.
Built with all-metal gears and aluminum shell for superior durability.
Water-resistant and compact, ideal for robotics and RC projects.
Operates at 4.8V–7.2V with fast 0.14s/60° response speed.
Compatible with Arduino, Raspberry Pi, and other PWM controllers.

Continuous rotation servos are like regular hobby RC servos but modified to offer speed control instead of position control. They're essentially compact, affordable motors with integrated motor drivers. Add a wheel, and you've got a simple drive system for your robot, controllable with an RC signal or directly connected to a single microcontroller I/O line.

Description
Product Details

Description

The TD-8120MG 360° Continuous Rotation Digital Servo Motor is engineered for high torque, smooth performance, and continuous motion control. Delivering up to 22.8kg.cm of stall torque at 7.2V, this servo combines strength and precision in a compact aluminum shell. Its 360° continuous rotation allows for precise speed and direction adjustments via PWM signals, making it ideal for mobile robots, RC vehicles, automation systems, and educational robotics. The all-metal gear construction ensures excellent durability, while the water-resistant design enhances reliability in outdoor and demanding environments. Whether used for drive mechanisms or rotational devices, the TD-8120MG provides consistent and versatile performance for advanced DIY and professional applications. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

360° Continuous Rotation: Allows for uninterrupted, full-circle motion for speed and direction control.
High Torque Output: Provides up to 22.8kg.cm torque at 7.2V for powerful mechanical drive.
Durable Construction: All-metal gears and CNC aluminum casing offer excellent strength and heat resistance.
Water-Resistant Design: Splashproof build for use in outdoor or dusty environments.
Fast and Smooth Response: 0.14s/60° rotation speed at 7.2V ensures accurate control.
PWM Control: Compatible with standard pulse-width modulation for easy programming.
Compact and Lightweight: Small form factor fits easily into robotics or RC systems.
Wide Voltage Range: Operates between 4.8V–7.2V for versatile power compatibility.
Reliable Performance: Delivers stable motion with low noise and minimal vibration.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

Robotics: Ideal for wheel drive or continuous rotation in mobile robots.
RC Vehicles: Perfect for propulsion, steering, and custom motion systems.
DIY Automation: Enables continuous motion in smart devices or mechanical builds.
STEM Education: Great for teaching robotics, electronics, and servo programming.
Industrial Control: Suitable for automated conveyor or rotating display mechanisms.
Home Projects: Use for camera pans, rotating platforms, or kinetic art installations.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specifications
Specification	Details
Model	TD-8120MG
Type	Digital High Torque Servo (360° Continuous Rotation)
Operating Voltage	4.8V – 7.2V
No-Load Speed	0.18 sec/60° (4.8V), 0.14 sec/60° (7.2V)
Running Current	210mA (4.8V), 260mA (7.2V)
Stall Current	2100mA ±10% (4.8V), 2700mA ±10% (7.2V)
Torque	20.5kg.cm (4.8V), 22.8kg.cm (7.2V)
Rotation Type	360° Continuous Rotation
Motor Type	Carbon Brush Motor
Gear Material	All-Metal
Casing Material	Aluminum Alloy
Control Signal	PWM (Pulse Width Modification)
Pulse Width Range	500–2500µs
Neutral Position	1500µs
Dead Band Width	5µs
Dimensions	40 × 20.5 × 40.5 mm
Weight	56g
Connector Wire Length	320mm
Water-Resistant	Yes
Shipment Weight	0.0848 kg
Shipment Dimensions	6 × 6 × 4 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

How to Use:

Power Supply:
- Use a power source between 4.8V–7.2V.
Wiring:
- Same wiring as the TD-8135MG.
Programming:
- Control using PWM commands:
  - myServo.write(0) for counterclockwise rotation.
  - myServo.write(180) for clockwise rotation.
  - Use values around myServo.write(90) to stop rotation.
Testing and Integration:
- Attach wheels, mechanical arms, or other components as needed.

Package Includes:

1 x TD-8120MG Digital High Torque Servo Motor Metal Gear 20kg 360° Continuous Rotation
