D-type flip-flops sharing a common clock and asynchronous clear input. Designed for data storage and synchronization in digital systems, it captures data on the rising edge of the clock and holds it until the next transition, making it ideal for use in registers, counters, and microprocessor-based control systems. With its reliable Low Power Schottky (LS) technology, the 74LS273 offers low power consumption and fast switching speeds. It’s commonly used in data buffering, bus interfacing, and sequential logic circuits. Packaged in a 20-pin DIP format, this IC is well-suited for both prototyping and industrial digital applications. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
Contains eight D flip-flops with common clock and clear inputs.
Edge-triggered operation for accurate data synchronization.
TTL LS-compatible logic for low power and high performance.
Asynchronous master clear input for quick data reset.
Suitable for registers, counters, and timing logic applications.
Compact 20-pin DIP package for easy circuit integration.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
Data storage and transfer registers.
Counters and sequential logic circuits.
Microprocessor and memory system interfacing.
Digital control and timing systems.
Educational and experimental logic design projects.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications |
| IC Type | Octal D Flip-Flop Register |
| Logic Family | LS TTL (Low Power Schottky) |
| Number of Flip-Flops | 8 |
| Trigger Type | Edge-Triggered (Rising Edge) |
| Control Inputs | Common Clock, Asynchronous Clear |
| Output Type | TTL-Compatible |
| Supply Voltage | 4.75V – 5.25V |
| Logic Compatibility | TTL |
| Propagation Delay | 20 ns typical |
| Power Consumption | Low (Schottky Design) |
| Package Type | DIP-20 |
| Operating Temperature Range | 0°C to +70°C |
| Typical Supply Current | 4 mA |
| Shipment Weight | 0.0016 kg |
| Shipment Dimensions | 4 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x IC 74LS273 Octal D Flip-Flop Register
