KK2.1.5 Multi-rotor LCD Flight Control Board With 6050MPU And Atmel 644PA Robotics Bangladesh
  • KK2.1.5 Multi-rotor LCD Flight Control Board With 6050MPU And Atmel 644PA Robotics Bangladesh

KK2.1.5 Multi-rotor LCD Flight Control Board With 6050MPU And Atmel 644PA

RBD-0959

  • IC: Atmega644 PA
  • Gyro/Acc: 6050MPU
  • Input Voltage: 4.8V~6.0V
  • AVR Interface: Standard 6 Pin
  • Signal From Receiver: 1520us(5 channels)
  • Signal to ESC: 1520 us
BDT 6,199.00
BDT 6,199.00 BDT 6,199.00 BDT 6,199.00 BDT 6,199.00
Tax included Tax excluded Tax included Tax excluded
BDT 6,199.00 Tax excluded
BDT 6,199.00 Tax included
BDT 0.00 Tax
BDT 6,199.00 Tax excluded
BDT 0.00 Tax
BDT 6,199.00 Tax included
Quantity
In-Stock
6 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

If you are wandering to become an Electronic geek and want to build some Cool Projects of Drone Then this module is for you. With this Control board, you can Enhance your Knowledge about Flight controllers as well as the working of the accelerometer and Gyroscope. The KK 2 Flight Controller Board with 6050 MPU Board and Atmel 644PA is the next generation of KK flight control boards. It comes preinstalled with the KK 2 firmware and features advanced processor technology from STMicroelectronics, sensor technology, InvenSense system delivering incredible performance, flexibility, and reliability for controlling any autonomous vehicle. A handy piezo buzzer is also included for audio warning when activating and deactivating the board. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

The LCD screen and built-in software make install and setup easier than ever. The KK gyro system has been updated to an incredibly sensitive 6050 MPU system making this the most stable KK board ever and allowing for the addition of an auto-level function. At the heart of the KK 2 is an Atmel Mega644PA 8-bit AVR RISC-based microcontroller with 64k of memory.

Note:

  1. This product is available in 2 types, having black & pink buttons, which will be shipped randomly. Most probably, you’ll get a board with pink buttons.
  2. It is always recommended to update to the latest software version as part of your initial setup. (this is different than v1.6 for 2.0)

Features:

  1. Auto Level
  2. Standard 6 Pin AVR Interface
  3. 1520us(5 channels) Signal from the receiver

Specification:

  1. Size: 50.5mm x 50.5mm x 12mm
  2. Weight: 21 gram (Inc Piezo buzzer)
  3. IC: Atmega644 PA
  4. Gyro/Acc: 6050MPU InvenSense Inc.
  5. Auto-level: Yes
  6. Input Voltage: 4.8-6.0V
  7. AVR interface: standard 6 pin.
  8. Signal from Receiver: 1520us (5 channels)
  9. Signal to ESC: 1520us

Firmware Version: 1.6:

  1. Pre-installed firmware., Dualcopter, Tricopter.
  2. Y6, Quadcopter +, Quadcopter X, Hexcopter +, Hexcopter X, Octocopter +, Octocopter X.
  3. X8 +, X8 X, H8, H6, V8, V6.
  4. Flying Wing.
  5. Singlecopter 2M 2S, Singlecopter 1M 4S.
  6. Custom Mix via the “Mixer Editor” option:
    • The Mixer Editor allows you to adjust where and how much signal the motors receive from stick input and sensors. This allows you to create any configuration possible with up to 8 motors or servos.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Model KK2
Input Voltage (V) 4.8V-6.0V
Firmware Pre-installed firmware
Sensors 6050 MCU
Processor Atmel 644PA
Micro-SD Card Slot No
Length (mm) 50.5
Width (mm) 50.5
Height (mm) 12
Weight (gm) 26
Shipment Weight 0.03 kg
Shipment Dimensions 6 × 6 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

  1. To know how to use KK 2 Flight controller
  2. To check how to update the Firmware version of KK Flight Controller

Package Includes:

1 x KK2.1.5 Multi-rotor LCD Flight Control Board With 6050MPU And Atmel 644PA

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-0959
6 Items

Specific References

EAN13
0959
