ZMCT103C 5A Range Single Phase AC Micro Current Transformer Sensor

RBD-1424

  • Onboard precision microcurrent transformer.
  • Onboard sampling resistor.
  • The module can measure AC currents less than 5A, the corresponding analog output 5A/5mA.
  • Rated input current: 5A
  • Rated output current: 5mA
  • Change: 1000: 1
  • The linear range: 0 ~ 10A (100 ohms)
  • Linearity: 0.2%
BDT 250.00
BDT 250.00 BDT 250.00 BDT 250.00 BDT 250.00
Tax included Tax excluded Tax included Tax excluded
BDT 250.00 Tax excluded
BDT 250.00 Tax included
BDT 0.00 Tax
BDT 250.00 Tax excluded
BDT 0.00 Tax
BDT 250.00 Tax included
Quantity
In-Stock
54 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

ZMCT103C AC current Sensor is the best for the purpose of the DIY project and industrial application, where we need to measure the accurate AC current with current transformer. This is an perfect choice to measure the AC current using Arduino/ESP8266/Raspberry Pi like an opensource platform. In many electrical projects, engineer directly deals with measurements with few basic requirements like, RoboticsBD

  • High galvanic isolation
  • High accuracy
  • Good Consistency

This is a high precision micro current Transformer. This module makes it easy to monitor AC mains current upto 5 Amps . ZMCT103 is  a pcb mount current transformer with 1000:1 turns ratio. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. On-board micro precision current transformer
  2. Onboard sampling strength
  3. The module can measure AC currents less than 5A, the corresponding analog output 5A/5mA
  4. Rated Input Current: 5A
  5. Rated output current: 5mA
  6. PCB size: 1.89cm*2.07cm*1.76cm
  7. Change: 1000: 1
  8. Linear range: 0 ~ 10A (100 ohms)
  9. Linearity: 0.2%
  10. Precision: 0.2
  11. Uses Insulation Voltage: 3000 V Measure
  12. Sealing material: epoxy resin
  13. Operating temperature: -40Celsius~ + 70 Celsius

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Rated Input Current (A) 5
Rated Output Current (mA) 5
The linear range 0 ~ 10A (100 ohms)
Change 1000: 1
Linearity 0.002
Precision Rating 0.2
Sealing material Epoxy Resin
Operating Temperature (°C) -40 to 90
Length (mm) 18
Width (mm) 19
Height (mm) 22
Weight (gm) 8
Shipment Weight 0.012 kg
Shipment Dimensions 3 × 3 × 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes :

1 x ZMCT103C 5A Range Single Phase AC Micro Current Transformer Sensor.
