Current Sensor ACS712-5A Robotics Bangladesh
  • Current Sensor ACS712-5A Robotics Bangladesh

Current Sensor ACS712-5A

RBD-1174

  • Low-noise analog signal path.
  • Device bandwidth is set via the new FILTER pin.
  • 5 µs output rise time in response to step input current.
  • Small footprint, low-profile SOIC8 package.
  • 2.1 kV RMS minimum isolation voltage from pins 1-4 to pins 5-8.
BDT 184.00
BDT 184.00 BDT 184.00 BDT 184.00 BDT 184.00
Tax included Tax excluded Tax included Tax excluded
BDT 184.00 Tax excluded
BDT 184.00 Tax included
BDT 0.00 Tax
BDT 184.00 Tax excluded
BDT 0.00 Tax
BDT 184.00 Tax included
Quantity
In-Stock
5 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

The 5A range Current Sensor Module ACS712 consists of a precise, low-offset, linear Hall circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field in which the Hall IC converts into a proportional voltage. RoboticsBD

Sensing and controlling current flow is a fundamental requirement in a wide variety of applications including, over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, programmable current sources, etc.  Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

This ACS721 current module is based on the ACS712 sensor, which can accurately detect AC or DC current.

The maximum AC or DC that can be detected can reach 5A, and the present current signal can be read via analog I / O port of Arduino.

Note: ACS712 is based on the Hall detection principle, please try to avoid the magnetic field, when using it as it may impact the reading accuracy.

Features :

  1. The low-noise analog signal path
  2. Device bandwidth is set via the new FILTER pin
  3. 5 µs output rise time in response to step input current
  4. Small footprint, low-profile SOIC8 package
  5. 2.1 kV RMS minimum isolation voltage from pins 1-4 to pins 5-8
  6. 5.0 V, single-supply operation
  7. 66 to 185 mV/A output sensitivity
  8. Output voltage proportional to AC or DC currents
  9. Factory-trimmed for accuracy
  10. Extremely stable output offset voltage
  11. Nearly zero magnetic hysteresis
  12. The radiometric output from the supply voltage.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Current sensor chip ACS712ELC-5A
Operating Voltage (V) 4.5V ~ 5.5V DC
Measure Current Range -5 ~ +5A
Sensitivity 100mV/A
Length (mm) 32
Width (mm) 13
Height (mm) 13.5
Weight (gm) 5
Shipment Weight 0.01 kg
Shipment Dimensions 4 × 2 × 2 cm

Please allow 5% measuring deviation due to manual measurement.
