MP-135 MP503 Air Quality Sensor Module Robotics Bangladesh
  • MP-135 MP503 Air Quality Sensor Module Robotics Bangladesh

MP-135 MP503 Air Quality Sensor Module

RBD-1751

  • Detection Gas: H2, Alcohol, CO, VOC
  • Detection Range: 10～500ppmH2 5～500ppm Alcohol 10～500ppm CO
  • Air Quality Sensor Module
BDT 590.00
BDT 590.00 BDT 590.00 BDT 590.00 BDT 590.00
Tax included Tax excluded Tax included Tax excluded
BDT 590.00 Tax excluded
BDT 590.00 Tax included
BDT 0.00 Tax
BDT 590.00 Tax excluded
BDT 0.00 Tax
BDT 590.00 Tax included
Quantity
In-Stock
12 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

MP135 gas sensor is for air quality. It adopts multilayer thick film manufacturing technology. The heater and metal oxide semiconductor material on the ceramic substrate of subminiature Al2O3 are fetched out by electrode down-lead, encapsulated in metal socket and cap. Conductivity of the sensor is affected by the concentration of target gas. The higher the concentration is, the higher conductivity of sensor gets. Users can adopt simple circuit to convert variation of conductivity into output signal corresponding to gas concentration. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. Combustible gas leak monitoring device
  2. Fire/safety detection system for home
  3. Factory and commercial use.
  4. Combustible gas leak alarm
  5. Gas leak detector

Features:

  1. Good sensitivity to methane
  2. Wide concentration range
  3. Strong anti-interference ability
  4. Low power consumption
  5. Fast responses recovery
  6. Good stability
  7. Long life
  8. Low cost
  9. Simple drive circuit

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specification
Model MP135
Sensor Type Semiconductor flat surfaced sensor
Standard Encapsulation Metal Cap
Detection Gas H2,Alcohol, CO
Detection range 10～500ppmH2 5～500ppm Alcohol 10～500ppm CO
Temperature, humidity 20℃±2℃；65%±5%RH
Shipment Weight 0.003 kg
Shipment Dimensions 5 × 5 × 2 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

  1. Datasheet

Package Includes:

1 x MP-135 MP503 Air Quality Sensor Module.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-1751
12 Items

Specific References

EAN13
1751
