12V Miniature Linear Actuator 150mm

RBD-2924

  • 150mm Stoke
  • Compact & Powerful
  • Ideal for space-limited applications
  • Suitable for small doors, furniture, robotics, drones, and various DIY projects.
  • Durable Construction.
BDT 4,995.00
BDT 4,995.00 BDT 4,995.00 BDT 4,995.00 BDT 4,995.00
Tax included Tax excluded Tax included Tax excluded
BDT 4,995.00 Tax excluded
BDT 4,995.00 Tax included
BDT 0.00 Tax
BDT 4,995.00 Tax excluded
BDT 0.00 Tax
BDT 4,995.00 Tax included
Quantity
In-Stock
15 Items

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

The 12V miniature linear actuator is a powerful and versatile solution for various applications requiring precise linear motion in a compact form factor. This actuator boasts a maximum thrust of 60N and a stroke length of 150mm, making it ideal for projects with limited space but demanding power needs. Featured By RoboticsBD.

Durable Construction:

Engineered for long-lasting performance, this actuator features a high-quality polyamide housing, a robust metal gearbox with wear-resistant gears, and an aluminum alloy telescopic tube and outer tube for excellent corrosion resistance.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. Compact Size: Saves space in space-constrained applications.
  2. Strong Thrust (60N): Delivers powerful force for various tasks.
  3. Multiple Speed & Stroke Options: Choose the ideal settings for your project.
  4. Durable Construction: Built to withstand demanding environments.
  5. Easy to Control: Simple power supply control with automatic stop and lock.
  6. Quiet Operation: Low noise levels (around 45dB-55dB).
  7. Advanced Protection: Water and dust resistant (IP54 rating).

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. Small doors and windows
  2. Furniture mechanisms (adjustable tables, reclining chairs)
  3. Medical and health equipment
  4. Agricultural machinery
  5. Robotics projects
  6. Drones and aircraft models
  7. Car and ship models

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specifications
Voltage 12V DC
Stroke 150mm
Installation Length 55mm + Stroke Length
No-Load Speed 15mm/s
Max. Load 60N
Stroke Rod Material Aluminum Alloy
Outer Tube Material Aluminum Alloy
Gear Material Steel Alloy
Motor Type Brushed DC Motor
Duty Cycle 10%
Plug Standard Standard two-core wire
Operating Temp. -26°C to 85°C
Operating Noise 45-55 dB (approx.)
Shipment Weight 0.085 kg
Shipment Dimensions 22 x 5 x 5 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Package Includes:

1 x 12V Miniature Linear Actuator 150mm

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Product Details
RBD-2924
15 Items

Specific References

EAN13
2924
