The VL53L1X Laser Ranging Sensor is a high-performance Time-of-Flight (ToF) module designed for precise and reliable distance measurement. With a maximum range of up to 4 meters and a fast measurement frequency of up to 50Hz, it is one of the fastest and most efficient ToF sensors available. Unlike traditional IR proximity sensors, the VL53L1X uses ST’s FlightSense™ technology, ensuring absolute distance measurement regardless of target color, material, or reflectance. Its 940nm Class 1 invisible laser emitter combined with a SPAD receiving array and infrared filters ensures robust performance even under challenging ambient lighting conditions. The sensor also supports programmable ROI, allowing developers to customize the field of view for multizone operation and enhanced flexibility. Its compact size, I²C interface, and software support make it ideal for seamless integration into robotics, IoT devices, drones, and consumer electronics. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
Long-Range Detection – Accurate ranging up to 4 meters.
High-Speed Performance – Supports up to 50Hz measurement frequency.
Advanced ToF Technology – Works independently of target color or reflectivity.
Programmable ROI – Adjustable field-of-view for multizone applications.
Compact & Easy to Integrate – Small form factor with reflowable package.
Seamless Operation – Reliable even under different ambient lighting and cover materials.
Low-Power Microcontroller – Efficient for IoT and battery-powered applications.
Compatibility – Pin-to-pin with VL53L0X for easy upgrades.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
Robotics – Obstacle detection, navigation, and mapping.
IoT Devices – Smart sensing in connected devices and automation.
Consumer Electronics – Proximity sensing for smartphones, tablets, and appliances.
Drones & UAVs – Altitude holding, collision avoidance, and terrain tracking.
Smart Home Systems – Presence detection and gesture recognition.
Industrial Automation – Precision measurement and material handling.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications |
| Model | VL53L1X |
| Sensor Type | Time-of-Flight (ToF) Laser Ranging Sensor |
| Module Size | 4.9 × 2.5 × 1.56 mm |
| Emitter | 940 nm invisible Class 1 laser |
| Receiver | SPAD array with integrated lens |
| Max Ranging Distance | Up to 400 cm (4m) |
| Ranging Frequency | Up to 50 Hz |
| Field-of-View (FoV) | 27° typical, programmable ROI |
| Integration | Reflowable single component module |
| Operating Voltage | 2.8V power supply |
| Interface | I²C (up to 400kHz) |
| Control Pins | Shutdown, Interrupt |
| Compatibility | Pin-to-pin with VL53L0X |
| Operating Conditions | Works under various cover materials & lighting |
| Application | Robotics, IoT, consumer electronics, drones |
| Shipment Weight | 0.0018 kg |
| Shipment Dimensions | 3 × 2 × 2 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x VL53L1X Laser Ranging Sensor Time-of-Flight (ToF)
