The R20DC USB RFID Card Reader is a dual-frequency (125KHz and 13.56MHz) proximity card reader that supports both RFID ID and IC cards. With plug-and-play USB functionality, this reader is recognized as an HID (Human Interface Device), eliminating the need for drivers or extra software. It works like a keyboard, outputting card numbers directly into any text field (e.g., Notepad, Word, Excel, or web forms).
The R20DC USB RFID Card Reader is a dual-frequency (125KHz and 13.56MHz) proximity card reader that supports both RFID ID and IC cards. With plug-and-play USB functionality, this reader is recognized as an HID (Human Interface Device), eliminating the need for drivers or extra software. It works like a keyboard, outputting card numbers directly into any text field (e.g., Notepad, Word, Excel, or web forms).
Compact, fast, and easy to use, the R20DC is widely used in access control systems, personal identification, attendance tracking, parking management, and more.
Dual Frequency Support: 125KHz (RFID ID cards) and 13.56MHz (IC cards, S50/S70)
Plug & Play: No drivers required; works as an HID device like a keyboard
Reading Distance: Up to 8 cm
Multi-System Compatibility: Windows 8/7/XP/2000, Linux, Vista, Android (via OTG)
Card Support: Reads ID (125KHz) and IC (13.56MHz S50/S70) card serial numbers
Easy to Use: Outputs card number directly into applications
Built-in Buzzer & LED: Audible and visual feedback for identification
OTG Support: Can connect to Android phones via OTG cable
Operating Frequency: 125KHz and 13.56MHz (2-in-1)
Reading Distance: 0 – 8 cm
Connection Interface: USB (HID, driver-free)
System Support: Windows 8/7/XP/2000, Linux, Vista, Android OTG
Card Types Supported: S50, S70, RFID ID & IC cards
Indicators: Built-in LED and buzzer
Connect the R20DC to a computer using the included USB cable.
Open a text editor (Notepad, Word, Excel, etc.).
Place a card near the reader (within 0–8 cm).
The card serial number will appear automatically on the screen.
Access control systems
Attendance and time tracking
Parking management
Production line identification
Personal authentication
Supermarket and office management
1 × R20DC 125KHz & 13.56MHz 2-in-1 USB Card Reader
1 × USB Cable
(Note: RFID cards or tags are not included and must be purchased separately.)
With dual-frequency support, driver-free HID operation, and universal compatibility, the R20DC USB RFID Reader is a reliable, cost-effective solution for a wide range of RFID-based identification and security applications.
Simplify your RFID projects with the R20DC — just plug in, scan, and go!
